ABB f204a-25/0.5 l 4p rcd 25a 500ma
MPN: 2CSF204123R4250
Alt. SKU: F204 A-25/0.5-L
Special Price
£151.43
£126.19
Regular Price
£252.38
Why Choose the F204 A-25/0.5-L [2CSF204123R4250]
The RCCBs F200 series assures protection to people and installations against fault current to earth. A large offer for standard instantaneous and selective AC and A types is completed with some configurations for special applications. This product is suitable for installations where neutral on the left is .
Technical Specification
- Function: Residual Current Device (RCCB) Type A for earth fault protection.
- Voltage Range: 195-440 V test voltage (Ut).
- Poles: 4P configuration with neutral terminal on the left.
- Operating Characteristic: Instantaneous tripping.
- Electrical Endurance: 10,000 operating cycles.
- Mechanical Endurance: 20,000 cycles.
- Terminal Type: Screw terminals with failsafe bi-directional cylinder-lift design.
- Connecting Capacity: Busbar 10 mm²; rigid and flexible wires 25 mm².
- Wire Stripping Length: 12 mm.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the function of the RCCB F200 series?
The RCCB F200 series functions as a Residual Current Device (RCCB) for earth fault protection.
What is the voltage range for the RCCB F200 series?
The voltage range is 195-440 V test voltage (Ut).
What is the configuration of the RCCB F200 series?
The RCCB F200 series has a 4P configuration with the neutral terminal on the left.
What is the connecting capacity for wires?
The connecting capacity is 10 mm² for busbar and 25 mm² for rigid and flexible wires.
What is the mechanical endurance of the RCCB F200 series?
The mechanical endurance is rated at 20,000 cycles.
What type of terminals does the RCCB F200 series use?
The RCCB F200 series uses screw terminals with a failsafe bi-directional cylinder-lift design.
What standards and approvals does the RCCB F200 series conform to?
See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CSF204123R4250 |
|---|---|
| Amperage | 25A |
| Number of Poles | 4 Pole |
| HS Code | 85363030 |
| Country of Manufacture | Italy |
| Manufacturer | ABB |
| Alternative Product SKU | F204 A-25/0.5-L |
| Barcode | 8012542821007 |
