ABB f202ac-63/0.5 2 pole rcd 63a 500ma
MPN: 2CSF202001R4630
Alt. SKU: F202 AC-63/0.5
Special Price
£125.34
£104.45
Regular Price
£208.90
Why Choose the F202 AC-63/0.5 [2CSF202001R4630]
The RCCBs F200 series assures protection to people and installations against fault current to earth. A large offer for standard instantaneous and selective AC and A types is completed with some configurations for special applications.
Technical Specification
- Function: Instantaneous residual current device (RCCB) for earth fault protection.
- Residual Current Type: Type AC.
- Rated Voltage: 110-254 V AC.
- Number of Poles: 2P.
- Maximum Surge Current: 0.25 kA.
- Electrical Endurance: 10,000 cycles.
- Mechanical Endurance: 20,000 cycles.
- Terminal Type: Screw terminals.
- Connecting Capacity: 0-25 mm² multi-wired, 25 mm² solid-core conductors.
- Wire Stripping Length: 12 mm.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the function of the RCCB F200 series?
The RCCB F200 series functions as an instantaneous residual current device (RCCB) for earth fault protection.
What type of residual current does the RCCB F200 series support?
The RCCB F200 series supports Type AC residual current.
What is the rated voltage for the RCCB F200 series?
The rated voltage for the RCCB F200 series is 110-254 V AC.
How many poles does the RCCB F200 series have?
The RCCB F200 series has 2 poles (2P).
What is the maximum surge current rating?
The maximum surge current rating is 0.25 kA.
What is the connecting capacity for conductors?
The connecting capacity is 0-25 mm² for multi-wired conductors and 25 mm² for solid-core conductors.
What is the electrical endurance of the RCCB F200 series?
The electrical endurance is rated for 10,000 cycles.
| Manufacturer Part Number | 2CSF202001R4630 |
|---|---|
| Amperage | 63A |
| Number of Poles | 2 Pole |
| Manufacturer | ABB |
| Alternative Product SKU | F202 AC-63/0.5 |
| Barcode | 8012542781103 |
