ABB f202ac-63/0.3 2 pole rcd 63a 300ma
MPN: 2CSF202001R3630
Alt. SKU: F202 AC-63/0.3
Special Price
£102.32
£85.27
Regular Price
£170.53
Why Choose the F202 AC-63/0.3 [2CSF202001R3630]
The RCCBs F200 series assures protection to people and installations against fault current to earth. A large offer for standard instantaneous and selective AC and A types is completed with some configurations for special applications.
Technical Specification
- Function: Residual Current Circuit Breaker (RCCB) for earth fault protection.
- Rated Voltage: 110-254 V AC.
- Rated Current & Type: Type AC residual current, instantaneous operation.
- Number of Poles: 2P.
- Maximum Surge Current: 0.25 kA.
- Operating Endurance: 10,000 electrical cycles, 20,000 mechanical cycles.
- Terminal Type: Screw terminals suitable for busbar (10 mm²), rigid and flexible wires up to 25 mm².
- Wire Stripping Length: 12 mm.
- Tightening Torque: 2.8 N·m.
- Mounting Width: 2 modular spacings on DIN rail.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the function of the RCCB F200 series?
The RCCB F200 series provides protection against fault current to earth for people and installations.
What is the rated voltage for the RCCB F200 series?
The rated voltage is 110-254 V AC.
What types of residual current does the RCCB F200 series support?
It supports Type AC residual current with instantaneous operation.
How many poles does the RCCB F200 series have?
The RCCB F200 series has 2 poles (2P).
What is the maximum surge current rating?
The maximum surge current rating is 0.25 kA.
What is the terminal type and cable capacity?
It has screw terminals suitable for busbar (10 mm²) and can accommodate rigid and flexible wires up to 25 mm².
What are the mounting specifications for the RCCB F200 series?
The RCCB can be mounted on a DIN rail, occupying 2 modular spacings.
| Manufacturer Part Number | 2CSF202001R3630 |
|---|---|
| Amperage | 63A |
| Number of Poles | 2 Pole |
| Manufacturer | ABB |
| Alternative Product SKU | F202 AC-63/0.3 |
| Barcode | 8012542780809 |
| Product Lead Time | Contact us for a delivery time before you order |
