ABB f202 b-25/0,03 2 pole rcd 25a 30ma
MPN: 2CSF202568R1250
Alt. SKU: F202 B-25/0.03
Why Choose the F202 B-25/0.03 [2CSF202568R1250]
The RCCBs F200 series assures protection to people and installations against fault current to earth. A large offer for standard instantaneous and selective AC and A types is completed with some configurations for special applications. This product is particularly suitable for the protection against smooth d.c. earth fault currents.
Technical Specification
- Function: Protection against residual earth fault currents including smooth d.c. faults (Type B).
- Rated Voltage: 170 to 253 V.
- Impulse Current Rating: 3000 A (8/20 µs).
- Dielectric Test Voltage: 2500 kV.
- Number of Poles: 2P.
- Operating Characteristic: 10 ms delay for high immunity.
- Terminal Type: Screw terminals with failsafe bi-directional cylinder-lift design.
- Connecting Capacity: Busbar 10 mm², Flexible and stranded conductors 1 to 25 mm².
- Mechanical Endurance: 20,000 cycles.
- Electrical Endurance: 10,000 cycles.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the primary function of the RCCBs F200 series?
The RCCBs F200 series provides protection against residual earth fault currents, including smooth d.c. faults (Type B).
What is the rated voltage for the RCCBs F200 series?
The rated voltage for the RCCBs F200 series is 170 to 253 V.
What is the maximum impulse current rating?
The maximum impulse current rating is 3000 A (8/20 µs).
How many poles does the RCCBs F200 series have?
The RCCBs F200 series is available in a 2-pole configuration.
What is the connecting capacity for conductors?
The connecting capacity is 10 mm² for busbar and 1 to 25 mm² for flexible and stranded conductors.
What is the mechanical endurance of the RCCBs F200 series?
The mechanical endurance is rated at 20,000 cycles.
What standards and approvals does the RCCBs F200 series conform to?
See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 2CSF202568R1250 |
|---|---|
| Amperage | 25A |
| Number of Poles | 2 Pole |
| HS Code | 85363030 |
| Country of Manufacture | Italy |
| Manufacturer | ABB |
| Alternative Product SKU | F202 B-25/0.03 |
| Barcode | 8012542341253 |
