ABB f202 a-63/0,3 2 pole rcd 63a 300ma
MPN: 2CSF202101R3630
Alt. SKU: F202 A-63/0.3
Special Price
£148.06
£123.38
Regular Price
£246.77
Why Choose the F202 A-63/0.3 [2CSF202101R3630]
The RCCBs F200 series assures protection to people and installations against fault current to earth. A large offer for standard instantaneous and selective AC and A types is completed with some configurations for special applications.
Technical Specification
- Function: Residual Current Circuit Breaker (RCCB) Type A, instantaneous operating characteristic.
- Rated Voltage: 110–254 V AC (Test Voltage), Maximum Operating Voltage UL/CSA 277 V AC.
- Number of Poles: 2P.
- Rated Leakage Current: 0.3 A.
- Terminal Type: Screw terminals with a stripping length of 12 mm.
- Connecting Capacity: Busbar 10 mm², rigid and flexible wires up to 25 mm².
- Mechanical Endurance: 20,000 cycles; Electrical Endurance: 10,000 cycles.
- Tightening Torque: 2.8 N·m.
- Number of Modular Spacings: 2 per DIN rail section.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the function of the RCCB F200 series?
The RCCB F200 series provides protection against fault current to earth for people and installations.
What types of RCCBs are available in the F200 series?
The F200 series includes standard instantaneous and selective AC and A types, along with configurations for special applications.
What is the rated voltage for the RCCB F200 series?
The rated voltage is 110–254 V AC, with a maximum operating voltage of 277 V AC (UL/CSA).
What is the connecting capacity for the RCCB F200 series?
The connecting capacity is 10 mm² for busbar and up to 25 mm² for rigid and flexible wires.
How many poles does the RCCB F200 series have?
The RCCB F200 series is available in a 2-pole configuration.
What is the tightening torque for the terminals?
The tightening torque for the terminals is 2.8 N·m.
What is the mechanical and electrical endurance of the RCCB F200 series?
The mechanical endurance is 20,000 cycles, and the electrical endurance is 10,000 cycles.
| Manufacturer Part Number | 2CSF202101R3630 |
|---|---|
| Amperage | 63A |
| Number of Poles | 2 Pole |
| HS Code | 85363030 |
| Country of Manufacture | Italy |
| Manufacturer | ABB |
| Alternative Product SKU | F202 A-63/0.3 |
| Barcode | 8012542783008 |
