ABB CR-U 91CV Varistor and LED Module
MPN: 1SVR405665R1100
Alt. SKU: CR-U 91CV
Special Price
£5.26
£4.38
Regular Price
£8.09
Why Choose the CR-U 91CV [1SVR405665R1100]
The CR-U 91CV plug-in module is a pluggable function module for the CR-U range sockets. This module provides overvoltage protection and a green LED indication. The rated control supply voltage is 110-230 V AC / 110 V DC.
Technical Specification
- Function: Pluggable overvoltage protection module for CR-U relay sockets with green LED indication.
- Rated Control Supply Voltage: 110 V DC / 110 ... 230 V AC / 110 ... 230 V AC/DC.
- Output Signal: None.
- Standards Compliance: CAN/CSA C22.2 No.14, IEC/EN 63000, IEC/EN 61984, UL 508.
- Category: Industrial electrical component accessory for interface relays.
- Weight: 0.007 kg.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the function of the CR-U 91CV module?
The CR-U 91CV module provides overvoltage protection for CR-U relay sockets and features a green LED indication.
What is the rated control supply voltage for the CR-U 91CV?
The rated control supply voltage is 110-230 V AC and 110 V DC.
Is the CR-U 91CV compatible with all CR-U relay sockets?
Yes, the CR-U 91CV is designed to be used with CR-U range sockets.
What are the dimensions and weight of the CR-U 91CV module?
The weight of the CR-U 91CV module is 0.007 kg. Dimensions are not specified; please refer to the manufacturer's documentation.
What standards does the CR-U 91CV comply with?
The CR-U 91CV complies with CAN/CSA C22.2 No.14, IEC/EN 63000, IEC/EN 61984, and UL 508.
Can the CR-U 91CV module be used in DC applications?
Yes, the module can be used in DC applications with a rated voltage of 110 V DC.
What type of output signal does the CR-U 91CV provide?
The CR-U 91CV module does not provide any output signal.
| Manufacturer Part Number | 1SVR405665R1100 |
|---|---|
| Manufacturer | ABB |
| Packed Quantity | 1 |
| HS Code | 85480090 |
| Barcode | 4013614529214 |
| Country of Manufacture | China |
| Alternative Product SKU | CR-U 91CV |
