ABB CR-S005VDC1RG PACK OF 10 Interface Relays

Why Choose the CR-S005VDC1RG [1SVR405501R1020]

The CR-S005VDC1RG is a slim pluggable interface relay, with gold-plated output contacts, which is suitable for direct mounting on a printed circuit board or use in conjunction with ABB's sockets. Plugged into a socket, the combination of relay and socket may be seemlessly snap-on mounted onto a DIN Rail. This relay operates with a 05 V DC rated control supply voltage and has a 1 c/o (SPDT) output with contacts rated at 250 V / 6 A.This slim pluggable interface relays may be used for electrical isolation, amplification and signal matching. Its gold-plated contacts ensure contact reliability particularly necessary in applications where small currents and loads are to be switched. The CR-S relays are 6.2 mm wide and therefore allow for the switching of high currents on a small footprint. Moreover, CR-S relays are UL 94-V0 certified, improving safety by providing high levels flame retardation. Screw and spring sockets, jumper bars and markers are available as accessories.

Technical Specification

• Function: Slim pluggable interface relay with gold-plated contacts.
• Control Supply Voltage: 5 V DC.
• Contact Configuration: 1 C/O (SPDT).
• Output Ratings: 250 V, 6 A.
• Operational Currents: AC-12: 6 A at 230 V; DC-12: 6 A at 24 V; DC-13: 1 A at 24 V.
• Degree of Protection: IP20.
• Dimensions: 6.2 mm wide slim design.
• Mounting: Direct PCB mounting or plug-in with ABB sockets for DIN Rail snap-on assembly.
• Standards & Certifications: CAN/CSA C22.2 No.14, IEC/EN 61810-1, UL 508.
• Flame Retardancy: UL 94-V0 certified for enhanced safety.
