ABB CR-P230AC2G Pack of 10 Pluggable Interface Relays
MPN: 1SVR405606R3000
Alt. SKU: CR-P230AC2G
Special Price
£86.11
£71.76
Regular Price
£132.48
Why Choose the CR-P230AC2G [1SVR405606R3000]
The CR-P230AC2G pluggable interface relay is suitable for direct mounting on a printed circuit board or use in conjunction with ABB's sockets. This relay operates with a 230 V AC rated control supply voltage and has a 2 c/o (SPDT) output with gold plated contacts rated at 250 V / 8 A. The gold plating ensures contact reliability for low load applications. enabling the possibility of switching multiple circuits with a single input signal. Coupled with a socket, the compact size of this relay offers possibilities to save space within a control panel. Furthermore, with an IP degree of 67, this relay offers complete protection against ingress of dust and airborne particles & protection against water and liquids, up to and including immersion in up to one meter of water. Standard sockets, logical sockets, pluggable function modules, holder and marker are available as accessories.
Technical Specification
- Function: Pluggable PCB interface relay with gold-plated contacts.
- Control Supply Voltage: 230 V AC rated.
- Output Configuration: 2 C/O (SPDT) contacts.
- Contact Rating: 250 V / 8 A.
- Insulation Voltage: Rated insulation voltage 400 V.
- Degree of Protection: IP67, dust tight and protected against immersion.
- Terminal Type: Soldering pins.
- Standards Compliance: IEC/EN 61810-1, UL/CSA rated 300 V AC, pilot duty B300.
- Flammability Rating: UL94 V-0.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the control supply voltage for the CR-P230AC2G relay?
The control supply voltage for the CR-P230AC2G relay is 230 V AC.
What is the output configuration of this relay?
The relay has a 2 c/o (SPDT) output configuration.
What is the contact rating of the CR-P230AC2G relay?
The contact rating is 250 V / 8 A.
What degree of protection does the relay offer?
The relay has an IP67 rating, providing complete protection against dust and immersion in water up to one metre.
Can the CR-P230AC2G relay be mounted directly on a PCB?
Yes, the relay is suitable for direct mounting on a printed circuit board.
Are there any accessories available for this relay?
Yes, standard sockets, logical sockets, pluggable function modules, holders, and markers are available as accessories.
What standards does the CR-P230AC2G relay comply with?
See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 1SVR405606R3000 |
|---|---|
| Manufacturer | ABB |
| Packed Quantity | 10 |
| HS Code | 85364900 |
| Amperage | 8A |
| Number of Poles | 2 Pole |
| Product Lead Time | Please contact us for a delivery time |
| Barcode | 4013614498336 |
| Country of Manufacture | Poland |
| Alternative Product SKU | CR-P230AC2G |
