ABB CR-P110AC2G Pack of 10 Pluggable Interface Relays

Why Choose the CR-P110AC2G [1SVR405606R7000]

The CR-P110AC2G pluggable interface relay is suitable for direct mounting on a printed circuit board or use in conjunction with ABB's sockets. This relay operates with a 110 V AC rated control supply voltage and has a 2 c/o (SPDT) output with gold plated contacts rated at 250 V / 8 A. The gold plating ensures contact reliability for low load applications. enabling the possibility of switching multiple circuits with a single input signal. Coupled with a socket, the compact size of this relay offers possibilities to save space within a control panel. Furthermore, with an IP degree of 67, this relay offers complete protection against ingress of dust and airborne particles & protection against water and liquids, up to and including immersion in up to one meter of water. Standard sockets, logical sockets, pluggable function modules, holder and marker are available as accessories.

Technical Specification

• Function: Pluggable PCB interface relay with gold-plated contacts.
• Control Supply Voltage: 110 V AC rated voltage.
• Output Contacts: 2 C/O (SPDT) contacts, rated 250 V / 8 A.
• Rated Operational Current: AC-12: 8 A at 230 V; AC-15: 3 A at 120 V, 1.5 A at 230 V; DC-12: 8 A at 24 V; DC-13: 2 A at 24 V, 0.1 A at 250 V.
• Insulation Voltage: Rated at 400 V.
• Degree of Protection: IP67 rated for dust-tight and water immersion protection.
• Terminal Type: Soldering pins for PCB mounting.
• Standards Compliance: IEC/EN 63000 and IEC/EN 61810-1 certified.
• Mounting: Suitable for direct PCB mounting or use with ABB sockets.
• Durability: Gold-plated contacts ensure reliability for low load applications.
