ABB CR-M110DC4 Pluggable Relay 4C/O 110VDC
MPN: 1SVR405613R8000
Alt. SKU: CR-M110DC4
Special Price
£7.57
£6.31
Regular Price
£11.65
Why Choose the CR-M110DC4 [1SVR405613R8000]
The CR-M110DC4 pluggable interface relay is a miniature relay, which is to be plugged into a suitable ABB CR-M socket. Plugged into a socket, the combination of relay and socket may be seemlessly snap-on mounted onto a DIN Rail.This relay operates with a 110 V DC rated control supply voltage and has a 4 c/o (SPDT) output with contacts rated at 250 V / 6A, enabling the possibility of switching multiple circuits with a single input signal. The relay has an integrated test button which is used for the manual actuation of the relay by locking it's output contacts. The test button facilitates easy testing and commissioning. The relay also has an integrated LED, which provides the visual indication of the energization of the relay coil. Standard sockets, logic sockets, pluggable function modules, holders and markers are available as accessories. Standard sockets, logical sockets, pluggable function modules, holder and marker are available as accessories.
Technical Specification
- Function: Pluggable miniature interface relay, 4 C/O (SPDT) contacts.
- Control Supply Voltage: 110 V DC.
- Operational Voltage: 250 V AC.
- Contact Ratings: 250 V / 6 A.
- Rated Operational Current AC-12: 6 A at 230 V.
- Rated Operational Current DC-12: 6 A at 24 V.
- Rated Insulation Voltage: 250 V.
- Degree of Protection: IP40.
- Terminal Type: Flat-pin connections.
- Mounting: Snap-on DIN Rail via ABB CR-M socket.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the control supply voltage for the CR-M110DC4 relay?
The control supply voltage for the CR-M110DC4 relay is 110 V DC.
What are the contact ratings for the relay?
The relay has contacts rated at 250 V / 6 A.
How is the CR-M110DC4 relay mounted?
The relay is mounted using a snap-on DIN Rail via an ABB CR-M socket.
What type of output does the relay provide?
The relay provides 4 c/o (SPDT) outputs, allowing multiple circuits to be switched with a single input signal.
Does the relay have any visual indicators?
Yes, the relay has an integrated LED that indicates the energisation of the relay coil.
What accessories are available for the CR-M110DC4 relay?
Standard sockets, logical sockets, pluggable function modules, holders, and markers are available as accessories.
What is the degree of protection for the relay?
The relay has a degree of protection rated at IP40.
| Manufacturer Part Number | 1SVR405613R8000 |
|---|---|
| Manufacturer | ABB |
| Packed Quantity | 1 |
| Amperage | 6A |
| Number of Poles | 4 pole |
| Product Lead Time | Please contact us for a delivery time |
| Barcode | 4013614497872 |
| Alternative Product SKU | CR-M110DC4 |
| Coil Voltage | 110VDC |
