ABB CR-M060DC4 Pack of 10 Pluggable Interface Relays
MPN: 1SVR405613R4200
Alt. SKU: CR-M060DC4
Special Price
£69.97
£58.31
Regular Price
£107.64
Why Choose the CR-M060DC4 [1SVR405613R4200]
The CR-M060DC4 pluggable interface relay is a miniature relay, which is to be plugged into a suitable ABB CR-M socket. Plugged into a socket, the combination of relay and socket may be seemlessly snap-on mounted onto a DIN Rail.This relay operates with a 60 V DC rated control supply voltage and has a 4 c/o (SPDT) output with contacts rated at 250 V / 6A, enabling the possibility of switching multiple circuits with a single input signal. The relay has an integrated test button which is used for the manual actuation of the relay by locking it's output contacts. The test button facilitates easy testing and commissioning. The relay also has an integrated LED, which provides the visual indication of the energization of the relay coil. Standard sockets, logic sockets, pluggable function modules, holders and markers are available as accessories. Standard sockets, logical sockets, pluggable function modules, holder and marker are available as accessories.
Technical Specification
- Function: Pluggable miniature interface relay, model CR-M060DC4.
- Control Supply Voltage: 60 V DC rated.
- Output Contacts: 4 changeover (SPDT) contacts.
- Contact Ratings: 250 V AC at 6 A.
- Terminal Type: Flat-pin connections.
- Insulation Voltage: Rated at 250 V.
- Degree of Protection: IP40.
- Mounting: Snap-on mounting on DIN rail via ABB CR-M socket.
- Standards Compliance: IEC/EN 61810-1, IEC/EN 63000, UL 508, CAN/CSA C22.2 No.14.
Trusted By Customers Worldwide
"Specified by UK panel builders for dependable control." Controls Engineer, UK
Frequently Asked Questions
What is the control supply voltage for the CR-M060DC4 relay?
The control supply voltage for the CR-M060DC4 relay is rated at 60 V DC.
How many output contacts does the CR-M060DC4 relay have?
The CR-M060DC4 relay has 4 changeover (SPDT) output contacts.
What is the maximum contact rating for the relay's outputs?
The contact ratings for the relay's outputs are 250 V AC at 6 A.
How is the CR-M060DC4 relay mounted?
The relay is mounted via snap-on mounting onto a DIN rail using a suitable ABB CR-M socket.
Does the CR-M060DC4 relay have any visual indicators?
Yes, it has an integrated LED that indicates the energization of the relay coil.
What accessories are available for the CR-M060DC4 relay?
Standard sockets, logic sockets, pluggable function modules, holders, and markers are available as accessories.
What standards does the CR-M060DC4 relay comply with?
See the manufacturer's data sheet for standards and approvals.
| Manufacturer Part Number | 1SVR405613R4200 |
|---|---|
| Manufacturer | ABB |
| Packed Quantity | 10 |
| HS Code | 85364900 |
| Barcode | 4013614497797 |
| Amperage | 6A |
| Number of Poles | 4 pole |
| Country of Manufacture | Poland |
| Alternative Product SKU | CR-M060DC4 |
| Coil Voltage | 60VDC |
