8A269024060C Finder Codesys Programmable Expansion Module
MPN: 8A.26.9.024.060C
Alt. SKU: 8A269024060C
Special Price
£193.88
£161.57
Regular Price
£258.50
Why Choose the Finder 8A.26.9.024.060C OPTA Expansion Module (Analogue, CODESYS)
The Finder 8A.26.9.024.060C is the CODESYS-compatible analogue expansion module for the OPTA platform. It offers 6 analogue inputs (configurable for 0-10 V, 4-20 mA or PT100) plus 2 analogue outputs (0-10 V or 4-20 mA) and 4 PWM outputs. Itâs designed to give you enhanced analogue I/O capacity in a compact DIN-rail module, ideal for building automation, machine control and panel upgrades.
At a Glance
- Analogue inputs: 6 channels - 0-10 V, 4-20 mA or PT100 (2- or 3-wire)
- Analogue outputs: 2 channels - 0-10 V or 4-20 mA
- PWM outputs: 4 channels
- Supply voltage: 12 to 24 V DC (Class 2 source)
- Mounting: DIN-rail EN 60715, open type, IP20 enclosure
- Typical ambient range: -20 Â CC to +50 Â CC, 5% to 95% RH, altitude up to 2000 m
Key Benefits
- Flexible analogue sensing: Configure each input for voltage, current or PT100 temperature sensing.
- Proportional outputs and PWM: Two analogue outputs plus four PWM channels allow fine control of valves, drives and actuators.
- CODESYS-ready: This variant supports CODESYS programming for IEC 61131-3 environments.
- Compact panel-friendly design: DIN-rail mounting keeps panel footprint small while providing advanced analogue I/O.
Technical Specifications
- Manufacturer: Finder S.p.A.
- Series / Model: OPTA expansion module - type 8A.26; part number 8A.26.9.024.060C
- Supply voltage (UN): 12-24 V DC (Class 2)
- Analogue inputs: 6 channels, 0-10 V / 4-20 mA / PT100 (2-wire or 3-wire)
- Analogue outputs: 2 channels, 0-10 V or 4-20 mA
- PWM outputs: 4 channels (external DC source typically 8-28.8 V)
- Mounting / Enclosure: DIN-rail EN 60715, open type, IP20 protection
- Operating temperature: -20 Â CC to +50 Â CC
Installation note: This module must be connected to an OPTA main CPU via the AUX port; it does not operate as a stand-alone device. Ensure the 12-24 V DC supply is stable and sized appropriately. Observe correct grounding and space for ventilation within the panel. Maintain ambient conditions within -20 Â CC to +50 Â CC. Always refer to the Finder datasheet for wiring details.
Frequently Asked Questions
How is this product installed or mounted?
It is designed for DIN-rail EN 60715, open type, IP20 enclosure installation, making it suitable for neat, modular wiring in control panels.
Is this product suitable for use in industrial control panels?
Yes. It is specified with an operating temperature range of -20 Â CC to +50 Â CC, which supports use inside suitably enclosed electrical panels.
What standards or safety ratings are stated for this product?
Relevant ratings are listed in the technical specifications, including: Typical ambient range -20 Â CC to +50 Â CC, 5% to 95% RH, altitude up to 2000 m; Flexible analogue sensing Configure each input for voltage, current or PT100 temperature sensing.. Refer to the manufacturer marking and datasheet for variant-specific approvals.
How many analogue outputs does it provide?
It supplies 2 analogue outputs, selectable as 0-10 V or 4-20 mA for proportional control tasks.
What are the PWM outputs for?
There are 4 PWM output channels, useful for controlling PWM-driven devices such as variable speed drives, actuators or fans.
Is this module stand-alone?
No - this is an expansion module and must be connected via the AUX port of an OPTA main module.
What is the operating temperature and mounting standard?
The module operates from -20 Â CC to +50 Â CC and mounts on DIN-rail EN 60715 in an IP20 enclosure.
| Manufacturer Part Number | 8A.26.9.024.060C |
|---|---|
| Alternative Product SKU | 8A269024060C |
| Manufacturer | Finder |
| Range | 8A |
| Barcode | 8012823458489 |
| HS Code | 85389091 |
| Rated current | 3A |
| Contact Configuration | 8 NO (SPST) |
| Max. peak current | 50A |
| Max. switching voltage (control contacts) | 33VDC |
| Rated voltage | 24VDC |
| Output operate/release time | 0.02/0.2ms |
| Nominal voltage DC | 12-24VDC |
| Operating range | 9.6-28.8VDC |
| PWM Outputs | 4 x 10kHz |
| Software Included | Codesys |
| Height | 84mm |
| Width | 70mm |
| Depth | 56.8mm |
| Packed Quantity | 1 |
| Country of Manufacture | Italy |
