8016416 Cembre DSVA800 ALUMINIUM SPLICE

DSVA800 Aluminium Splice Connector: Reliable Power Distribution in Demanding Environments

The DSVA800 Aluminium Splice Connector (SKU: 8016416) is engineered for secure and efficient power distribution in industrial applications. Designed to meet stringent DIN standards, this butt connector guarantees dependable performance even in challenging conditions, from -50°C to +150°C.

Key Features

• High-temperature resistance up to 150°C
• Compliant with DIN 46267 part 2 and DIN EN 50182 standards
• Aluminium conductor body with 99.5% purity for optimal conductivity
• Easy insertion input for streamlined installation
• Closed barrel design with CONTACTEM C3 grease for enhanced corrosion protection
• Clear markings for accurate identification and crimping

Technical Specifications

• Part Number: 8016416
• Cat Number: DSVA800
• Minimum Operating Temperature: -50°C
• Maximum Operating Temperature: 150°C
• Connector Type: Butt Connector
• Maximum Operating Voltage: 10,000V
• Conductor Material: Aluminium (99.5% purity)
• Internal Diameter: 36.3mm - 40mm
• Length (L): 350mm
• Width (A): 168mm
• Diameter (): 40mm
• Cable Stripping Length: 184.8mm
• Customs Code: 85369010

Applications

• Industrial power distribution
• Panel building
• High-temperature environments
• Maintenance and repair applications
