8010197 Cembre PKE308 INSULATED END SLEEVE (YELLOW)

PKE308 Yellow Insulated End Sleeve (0.1 - 0.3mm²) - Enhanced Safety & Reliability for Your Wiring

The PKE308 Yellow Insulated End Sleeve provides a secure and reliable crimp connection for wires ranging from 0.1 to 0.3mm². Engineered for demanding applications, these halogen-free sleeves offer superior insulation and protection against electrical hazards, ensuring long-lasting performance and compliance with industry standards.

Key Features

• Enhanced Safety: Halogen-free construction minimizes fire risks and toxic fumes in case of overheating.
• Reliable Crimping: Easy insertion input and annealed copper conductor ensure a strong and stable connection.
• High-Temperature Resistance: Withstands operating temperatures up to 105°C and short periods at 130°C.
• Durable Insulation: Polyamide PA6 insulated cover provides excellent dielectric strength (16.5 kV/mm).
• Compliant Design: Meets relevant industry standards for assured performance and safety (ETIM Class 7: Cable end sleeve [EC000005]).
• Clear Identification: Vibrant yellow color allows for easy circuit identification and troubleshooting.

Technical Specifications

• SKU: 8010197
• Part Number: PKE308
• Wire Range: 0.1 - 0.3 mm²
• Operating Temperature: -20°C to 105°C (130°C short periods)
• Insulation Material: Polyamide PA6 (Yellow)
• Conductor Material: Electrolytic copper (99.95% purity)
• Dielectric Strength: 16.5 kV/mm
• Flammability Rating: UL 94 V2
• Halogen-Free: Yes

Applications

• Panel building
• Industrial control systems
• Automotive wiring
• Maintenance and repair
• Lighting installations
