7GN2526U - CAM SWITCH GN2526U 48X48 FRONT MOUNTING
MPN: 7GN2526U
Special Price
£40.92
£34.10
Regular Price
£68.20
Why Choose the 7GN2526U?
The Lovato 7GN2526U motor starting switch is a rotary cam design for reliable 3‑phase motor reversing with spring return. Rated Ith 25 A and built on the 7GN round-shaped contact block series, it features U front mounting with a black handle and a compact 48 x 48 mm front plate. Product type designation 7GN25 and switching diagram 26 ensure straightforward specification and panel integration.
With a 6 kV rated impulse withstand voltage and IP40 frontal protection, the 7GN2526U suits protected industrial panels. Operating from -25 to +55 °C, it supports dependable service across typical plant environments. Conformity to IEC/EN/BS 60947-1, 60947-3 and 60947-5-1, plus UL and CSA standards, streamlines compliance for OEMs and panel builders.
Key Benefits
- 3-phase reversing cam with spring return for clear motor direction control.
- 25 A Ith rating for reliable motor starting and reversing duties.
- Front mounting with black handle simplifies panel installation and operation.
- Compact 48 x 48 mm front plate saves valuable door space.
- IP40 frontal protection for use in protected enclosures and cabinets.
- 6 kV impulse withstand improves resilience to transient overvoltages.
- Operates from -25 to +55 °C for varied ambient conditions.
- Compliant with IEC/EN/BS 60947 series, UL and CSA standards.
Technical Specification
- Product type designation: 7GN25
- Rated impulse withstand voltage Uimp: 6 kV
- Operating temperature: -25 to +55 °C
- Storage temperature: -40 to +70 °C
- IP degree (frontal): IP40
What’s Included
- Lovato 7GN2526U rotary cam switch, assembled
- 48 x 48 mm front plate with black handle
- Manufacturer datasheet (downloadable)
Applications
- Forward/reverse control of 3-phase motors
- Machine tools and conveyor direction control
- Panel-mounted motor control stations
- Maintenance and commissioning rotation checks
Frequently Asked Questions
What does switching diagram 26 indicate?
It denotes a 3‑phase motor reversing function with spring return. The handle returns to its initial position after actuation.
Is the 7GN2526U suitable for front mounting?
Yes. Mounting form U specifies front mounting with a black handle.
What are the key electrical ratings?
It has an Ith of 25 A and a rated impulse withstand voltage Uimp of 6 kV.
What are the front plate size and protection rating?
The front plate is 48 x 48 mm and the frontal protection is IP40.
Which standards does this switch conform to?
IEC/EN/BS 60947-1, 60947-3, 60947-5-1, UL60947-4-1 and CSA C22.2 n° 14.
Safety note: Install and commission only by qualified personnel. Isolate all power before work; IP40 is frontal only—use a suitable enclosure and follow IEC/EN and local regulations.
| Manufacturer Part Number | 7GN2526U |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85365080 |
| Barcode | 3850144005204 |
