7GN2098U - AMMETER SELECTOR (R-S-T) FRONT MOUNTING
MPN: 7GN2098U
Special Price
£31.06
£25.88
Regular Price
£51.77
Why Choose the 7GN2098U?
Lovato 7GN2098U is a 7GN series rotary cam ammeter switch within the voltmeters and ammeters range. Built for panel builders, it provides Switching diagram 98 and a 20 A IEC conventional free air thermal current (Ith). The U mounting form supports front mounting with a black handle and a compact 48X48 mm front plate. A round-shaped 7GN contact block and a rated impulse withstand voltage of 6 kV ensure dependable operation.
Designed for reliable panel integration, this unit carries product type designation 7GN20 and offers IP40 frontal protection. It operates from -25 to +55 °C, with storage from -40 to +70 °C, matching industrial environments. Compliance with IEC/EN/BS 60947-1, 60947-3, 60947-5-1, UL60947-4-1 and CSA C22.2 n° 14 supports specification in regulated projects. As part of Lovato’s 7GN family with a round-shaped contact block, it delivers a neat, space-saving 48x48 mm interface.
Key Benefits
- 20 A IEC conventional free air thermal current (Ith) supports robust ammeter circuits.
- Switching diagram 98 dedicated to precise ammeter switching operations.
- U front mounting with black handle for straightforward panel installation.
- Compact 48x48 mm front plate saves space on crowded fascias.
- 6 kV rated impulse withstand voltage (Uimp) enhances dielectric resilience.
- IP40 frontal protection suitable for enclosed or sheltered control panels.
- Operates -25 to +55 °C; stores -40 to +70 °C for flexibility.
- Conforms to IEC/EN/BS, UL and CSA standards for assured compliance.
Technical Specification
- Product type designation: 7GN20
- Rated impulse withstand voltage Uimp: 6 kV
- Operating temperature: -25 to +55 °C
- Storage temperature: -40 to +70 °C
- IP degree (frontal): IP40
What’s Included
- Lovato 7GN2098U ammeter switch unit
- 48x48 mm front plate with black handle (pre-fitted)
- Manufacturer datasheet (download via product page)
- Basic installation and safety information
Applications
- Ammeter selection and switching in control circuits
- Front-mounted measurement switching in control panels
- Switchboards requiring compact 48x48 mm operator interface
- Equipment operating within -25 to +55 °C ambient range
- Panels where IP40 frontal protection is adequate
Frequently Asked Questions
What is the switching function of the 7GN2098U?
It uses Switching diagram 98, indicating an ammeter switch configuration.
What current rating does this ammeter switch support?
The IEC conventional free air thermal current (Ith) is 20 A.
How is the device mounted and what is the front size?
Mounting form U supports front mounting with a black handle and a 48X48 mm front plate.
What are the protection and operating temperature ratings?
The frontal degree is IP40, with an operating range from -25 to +55 °C.
Which standards does the product conform to?
It conforms to IEC/EN/BS 60947-1, 60947-3, 60947-5-1, UL60947-4-1 and CSA C22.2 n° 14.
