ACS55-01N-04A3-2 ABB 0.75kW Three Phase ABB ACS55 Variable Speed Drive
MPN: ACS55-01N-04A3-2
Alt. SKU: 68878438
Why Choose the ABB 68878438 Drive Control Panel?
The ABB 68878438 is a reliable operator control panel designed for ABB variable frequency drives, providing engineers and technicians with a convenient local interface for configuring, monitoring and controlling drive systems. The panel enables fast access to operational parameters, system diagnostics and drive status information during commissioning and maintenance.
As part of ABB’s professional drive accessory portfolio, this control panel allows operators to adjust drive settings, monitor system performance and identify faults quickly. It is commonly used within industrial motor control installations where local drive interaction is required for setup and troubleshooting.
Designed for demanding industrial environments, the panel supports dependable operation across automation applications such as manufacturing machinery, HVAC systems, pumping installations and material handling equipment.
Key Advantages
- Provides local monitoring and control of ABB variable frequency drives.
- Supports drive parameter configuration and commissioning.
- Displays drive status, alarms and operational information.
- Enables fast diagnostics and troubleshooting during maintenance.
- Seamless integration with compatible ABB drive systems.
- Improves operational efficiency by providing direct access to drive settings.
Key Features
- Drive operator control panel for ABB drives.
- Supports parameter editing and drive configuration.
- Provides real-time monitoring and diagnostics.
- Designed for industrial automation environments.
- Allows quick commissioning and maintenance access.
- Compatible with selected ABB drive models.
Technical Specifications
- Manufacturer: ABB
- Part number: 68878438
- Product type: Drive operator control panel
- Function: Drive monitoring, parameter configuration and diagnostics
- Compatibility: Selected ABB variable frequency drives
- Interface: Drive communication interface
- Mounting: Drive-mounted or remote installation depending on system configuration
- Application: Industrial motor control and automation systems
- Primary use: Drive commissioning, monitoring and maintenance
Industrial Drive Control and Monitoring
Variable frequency drives are widely used in modern industrial automation to control motor speed, optimise energy consumption and improve overall system efficiency. Operator control panels allow engineers to configure drive parameters, monitor performance and identify faults directly at the drive location without requiring external software.
Reliable accessories such as ABB drive control panels are commonly installed alongside industrial variable speed drives to simplify system commissioning, improve maintenance workflows and provide real-time visibility of motor control performance.
Typical Applications
- Commissioning and configuration of ABB drive systems.
- Industrial motor control installations.
- HVAC fan and pump drive control systems.
- Material handling and conveyor automation.
- Manufacturing equipment and process automation.
Frequently Asked Questions
What is the ABB 68878438 control panel used for?
This operator panel allows engineers to monitor, configure and control compatible ABB variable frequency drives.
Can the panel be used during drive commissioning?
Yes. Engineers commonly use the panel to configure parameters, start or stop the drive and monitor system performance during commissioning.
Does the panel display drive alarms or faults?
Yes. The panel provides access to drive status information, alarms and diagnostic data to assist with troubleshooting.
Is this panel compatible with all ABB drives?
Compatibility depends on the specific drive series. The panel is designed for use with selected ABB variable frequency drive models.
Where is the control panel installed?
It can be mounted directly on the drive or installed remotely depending on the drive model and installation requirements.
Trusted by Automation Engineers
ABB drive accessories are widely used by engineers and system integrators to simplify commissioning, monitoring and maintenance of industrial motor control systems.
| Manufacturer Part Number | ACS55-01N-04A3-2 |
|---|---|
| Barcode | 6410038784416 |
| Packed Quantity | 1 |
| Height | 170mm |
| Width | 67.5mm |
| Depth | 128mm |
| Amperage | 4.3A |
| Number of analogue inputs | 1 |
| Number of digital inputs | 3 |
| Number of digital outputs | 1 |
| Input Phases | Single Phase |
| Input Frequency | 50/60Hz |
| Degree of protection (IP) | IP20 |
| KW Rating | 0.75kW |
| Number of HW-interfaces other | 1 |
| Output Frequency | 250Hz |
| Output Voltage | 240VAC |
| Output Phases | Three phase |
| Type of Converter | U converter |
| Relative symmetric net frequency tolerance | 5% |
| Relative symmetric net voltage tolerance | 10% |
| Voltage | 200/240VAC |
| VSD Range | ABB ACS55 |
| With PC connection | Yes |
| Manufacturer | ABB |
| Alternative Product SKU | 68878438 |
