51ADX0190B - SOFT STARTER ADX0190B
MPN: 51ADX0190B
Special Price
£7,026.49
£5,855.41
Regular Price
£8,266.46
Why Choose the 51ADX0190B?
The Lovato 51ADX0190B soft starter delivers advanced, three-phase control for severe duty applications, with a starting current up to 5•Ie and an integrated by-pass contactor. Rated at 190A Ie and supporting 208…500VAC operational voltage, it manages motors to 55 kW at 230VAC, 90 kW at 400VAC and 132 kW at 500VAC. A 208…240VAC supply range simplifies integration in common control panels.
Smart features include motor current thermal protection, current-limit starting, torque control, kick start and dynamic braking for precise acceleration and stopping. A PTC input, event log and RS232 interface streamline protection, diagnostics and commissioning. Built for industrial compliance, it conforms to IEC/EN 60947-1 and 60947-4-2, with IP00 protection and Pollution Degree 3, and a storage temperature range of −30 to +70 °C.
Key Benefits
- Severe duty starting capability up to 5•Ie for demanding motor loads.
- Integrated by-pass contactor reduces heat and losses during steady state.
- Wide 208…500VAC operational range for flexible three-phase installations.
- 190A rated starter current supports high-power motors up to 132 kW.
- Current limit, torque control, kick start and dynamic braking improve control.
- Built-in motor thermal protection and PTC input enhance motor safety.
- RS232 connectivity and event log simplify setup, monitoring and diagnostics.
Technical Specification
- Storage temperature: -30 to +70 °C
- Pollution degree: 3
- IP degree of protection: IP00
What’s Included
- Lovato ADX soft starter 51ADX0190B, 190A, with integrated by-pass contactor.
- User documentation and installation guidance.
- Built-in RS232 interface for configuration and diagnostics.
Applications
- Three-phase motor systems requiring severe duty starts with 5•Ie capability.
- Installations needing current-limited starting, torque control and dynamic braking.
- Panels operating on 208…500VAC with 208…240VAC control supply.
- Projects demanding event logging and RS232 for commissioning and diagnostics.
Frequently Asked Questions
What is the rated starter current Ie of the 51ADX0190B?
The rated starter current Ie is 190A.
Does this soft starter include a by-pass contactor?
Yes, it has an integrated by-pass contactor.
What motor power can it handle at 400VAC and 500VAC?
It supports 90 kW at 400VAC and 132 kW at 500VAC.
What are the supply and operational voltage ranges?
Supply is 208–240VAC; operational voltage is 208–500VAC.
Which protection and control functions are available?
It provides thermal protection, current limit start, torque control, kick start, dynamic braking, PTC input, event log and RS232.
Safety note: This IP00 device must be installed in a suitable enclosure and commissioned by qualified personnel in accordance with IEC/EN 60947 and the manufacturer’s instructions.
| Manufacturer Part Number | 51ADX0190B |
|---|---|
| Manufacturer | Lovato |
| HS Code | 85371098 |
| Barcode | 8013975075395 |
