4298037 Cembre TERMO-ROLL H3-180-25-YE1
MPN: 4298037
Alt. SKU: H3-180-25-YE1
Special Price
£1.25
£1.04
Regular Price
£1.56
4298037 Cembre TERMO-ROLL H3-180-25-YE1 is available to buy in increments of 1000
Why Choose the TERMO-ROLL H3-180-25-YE1?
The TERMO-ROLL H3-180-25-YE1 heat shrink tubing offers reliable cable protection and identification in demanding industrial environments. Its 3:1 shrink ratio ensures a tight, secure fit over a wide range of cable diameters, while its robust irradiated polyolefin construction provides excellent resistance to abrasion, chemicals, and temperature extremes. Compliant with relevant industry standards, this yellow heat shrink tubing is ideal for professional electricians, panel builders, and maintenance engineers.
Key Features
- Reliable Protection: Shields cables from abrasion, moisture, and chemicals.
- High Temperature Resistance: Operates effectively from -55°C to 135°C.
- 3:1 Shrink Ratio: Accommodates cable diameters from 6.5mm to 17mm (16mm² to 50mm² cross-section).
- Clear Identification: Bright yellow color enhances visibility and organization.
- Easy Application: Compatible with the ROLLY3000 printer for clear and permanent marking.
- Compliant with Standards: Meets industry requirements for safety and performance. (See technical specifications for details)
Technical Specifications
- Part Number: 4298037
- Catalog Number: H3-180-25-YE1
- Minimum Operating Temperature: -55°C
- Maximum Operating Temperature: 135°C
- Silicone-Free: No
- Halogen-Free: No
- Minimum Shrink Temperature: 90°C
- Storage Temperature: 10°C to 25°C
- Storage Duration: 720 days
- Relative Humidity of Storage: 45% to 55%
- Customs Code: 39173200
- ETIM Class 7: Cable coding system [EC001530]
- Compatible Ribbon: TRR-055; TRPR-060 PREMIUM
- Cable Housing Diameter Range: 6.5mm to 17mm
- Cable Cross Section Range: 16mm² to 50mm²
- Color: Yellow
- Material: Irradiated Polyolefin
- Length (L): 25mm
- Shrinkage Ratio: 3:1
- Gross Weight: 1.224g
- Software Code: 4962
- Printable with: ROLLY3000
Applications
- Panel Building: Provides secure and organized wiring within electrical panels.
- Industrial Maintenance: Repairs and protects damaged cable insulation.
- Cable Harnessing: Bundles and protects wires in automotive and aerospace applications.
- General Electrical Installations: Offers reliable insulation and strain relief for wiring in various environments.
The H3-180-25-YE1 accommodates cable diameters ranging from 6.5mm to 17mm, corresponding to cross-sectional areas of 16mm² to 50mm².
Yes, this tubing is compatible with the ROLLY3000 printer for clear and permanent marking.
Frequently Asked Questions
What makes this product special?
This product meets strict compliance and is made from robust irradiated polyolefin, providing reliable performance in demanding environments.
| Manufacturer | Cembre |
|---|---|
| Manufacturer Part Number | 4298037 |
| Colour | Yellow |
| Country of Manufacture | Denmark |
| HS Code | 39173200 |
| Alternative Product SKU | H3-180-25-YE1 |
| Barcode | 8016692614427 |
| Packed Quantity | 1000 |
