ACS880-14-585A-3 ABB 315kW Three Phase ABB ACS880 Variable Speed Drive

Why Choose the ABB ACH580-01-038A-4 HVAC Drive?

The ABB 3AXD50000042309, also identified as the ACH580-01-038A-4, is a high-efficiency HVAC variable frequency drive (VFD) designed to control motors used in heating, ventilation and air-conditioning systems. As part of the advanced ABB ACH580 HVAC drive platform, it delivers reliable motor speed control while helping building operators reduce energy consumption and optimise environmental performance.

Rated for approximately 18.5 kW motor power with a nominal output current of 38 A, the drive operates on a 380–480 V three-phase power supply. It is engineered specifically for HVAC equipment such as ventilation fans, chilled water pumps and air handling units where efficient and stable motor control is essential.

The ACH580 drive series integrates specialised HVAC functionality including pump and fan control macros, built-in PID control and energy optimisation features. These capabilities simplify commissioning and enable seamless integration with building management systems used in commercial and industrial facilities.

Key Advantages

• Purpose-built HVAC variable frequency drive for building automation systems.
• 18.5 kW motor control capability suitable for large fans and pumps.
• Operates on 380–480 V three-phase supply.
• Integrated HVAC control macros for simplified setup.
• Improves energy efficiency and operational reliability.
• Part of the trusted ABB ACH580 HVAC drive platform.

Key Features

• ACH580 HVAC variable frequency drive.
• 18.5 kW rated motor power.
• 38 A nominal output current.
• 380–480 V three-phase input supply.
• Integrated PID controller for HVAC process regulation.
• Built-in Modbus RTU communication.
• Optional fieldbus protocols including BACnet, PROFINET and EtherNet/IP.
• Wall-mounted enclosure suitable for plant room installations.

Technical Specifications

• Manufacturer: ABB
• Series: ACH580 HVAC Drives
• Model: ACH580-01-038A-4
• Product number: 3AXD50000042309
• Product type: HVAC variable frequency drive
• Rated output power: 18.5 kW
• Nominal output current: 38 A
• Input voltage: 380–480 V AC
• Input phase: 3-phase
• Output frequency range: 0–500 Hz
• Protection rating: IP21 / NEMA Type 1
• Mounting type: Wall-mounted
• Motor compatibility: Induction, permanent magnet and synchronous reluctance motors
• Typical applications: HVAC fans, pumps, air handling units and cooling systems

Energy Efficient HVAC Motor Control

Variable frequency drives are widely used in building automation systems to regulate airflow and water circulation efficiently. By adjusting motor speed according to system demand, HVAC drives significantly reduce energy consumption while improving system stability and extending equipment lifespan.

The ABB ACH580 series is engineered specifically for HVAC installations and integrates seamlessly with building management systems. Advanced control algorithms and communication capabilities allow engineers to optimise system efficiency across commercial buildings, hospitals, data centres and industrial facilities.

Typical Applications

• Air handling units (AHU).
• HVAC ventilation fan systems.
• Heating and chilled water pump control.
• Cooling tower fan drives.
• Commercial and industrial building automation systems.

Trusted by Building Automation Engineers

ABB ACH580 HVAC drives are widely trusted by engineers and facility managers for delivering reliable motor control and energy-efficient operation in modern building automation systems.
