ACS580-01-07A3-4+B056 ABB 3kW Three Phase ABB ACS580 Variable Speed Drive
MPN: ACS580-01-07A3-4+B056
Alt. SKU: 3AXD50000038968
£1,404.00
£1,170.00
Why Choose the ABB ACS880-01-169A-4 Industrial Drive?
The ABB 3AXD50000038968 corresponds to the ACS880-01-169A-4 industrial variable speed drive, part of ABB’s advanced ACS880 all-compatible drive platform. Designed for demanding industrial automation environments, this drive delivers precise motor control, high reliability and energy-efficient performance for a wide range of motor-driven processes.
Delivering approximately 90 kW rated motor power with a 169 A output current, the drive operates from a 380-480 V three-phase supply. It is suitable for controlling heavy industrial equipment such as pumps, conveyors, compressors and process machinery requiring dependable torque and speed regulation.
The ACS880 platform incorporates ABB’s advanced Direct Torque Control (DTC) technology, providing extremely fast torque response and precise motor control. This technology allows the drive to control virtually any type of AC motor while maintaining high efficiency and stable process operation.
Key Advantages
- High-performance 90 kW industrial AC drive for demanding machinery.
- 169 A continuous output current for heavy motor loads.
- Advanced Direct Torque Control (DTC) for precise torque regulation.
- Designed for 380-480 V three-phase industrial power systems.
- Reliable operation in harsh industrial environments.
- Part of ABB’s scalable ACS880 industrial drive platform.
Key Features
- ACS880-01 industrial variable speed drive.
- 90 kW rated motor power.
- 169 A continuous output current.
- 380-480 V AC three-phase supply.
- High precision motor control using DTC technology.
- Supports induction, permanent magnet and synchronous reluctance motors.
- Compact wall-mounted industrial drive design.
- Flexible communication and automation integration.
Technical Specifications
- Manufacturer: ABB
- Series: ACS880 Industrial Drives
- Model: ACS880-01-169A-4
- Product ID: 3AXD50000038968
- Drive type: Low voltage AC variable frequency drive
- Rated motor power (IEC): 90 kW
- Rated output current: 169 A
- Input voltage: 380-480 V AC
- Input phases: Three-phase
- Supply frequency: 50 / 60 Hz
- Control method: Direct Torque Control (DTC)
- Typical enclosure class: IP21 (options available)
- Mounting type: Wall mounted
- Typical applications: Pumps, compressors, conveyors and industrial machinery
Industrial Motor Control Performance
Industrial processes require reliable motor control systems capable of handling continuous operation and varying load conditions. ABB ACS880 drives combine advanced control algorithms with robust hardware to deliver stable performance across demanding industrial environments.
The ACS880 drive family is designed to control virtually any AC motor type and integrates extensive connectivity options for modern automation systems, enabling seamless integration with PLCs, fieldbus networks and industrial control platforms.
Typical Applications
- Industrial pump and compressor systems.
- Material handling and conveyor equipment.
- Manufacturing and process machinery.
- Water and wastewater treatment plants.
- Heavy industrial automation systems.
Frequently Asked Questions
What is the ABB 3AXD50000038968 used for?
This product is an ACS880 industrial variable frequency drive used to control AC motors in demanding industrial automation and process applications.
What motor size can this drive control?
The drive supports motors up to approximately 90 kW with a rated output current of 169 A.
What voltage supply does this drive require?
The ACS880-01-169A-4 operates from a 380-480 V three-phase AC power supply.
What is Direct Torque Control?
Direct Torque Control (DTC) is ABB’s advanced motor control technology that provides extremely fast torque response and precise motor performance.
Where are ACS880 drives typically installed?
They are widely used in industrial environments such as manufacturing plants, water treatment facilities, mining operations and heavy machinery installations.
Trusted by Industrial Automation Engineers
ABB ACS880 industrial drives are widely trusted by engineers worldwide to deliver precise motor control, high reliability and efficient operation in demanding industrial environments.
| Manufacturer Part Number | ACS580-01-07A3-4+B056 |
|---|---|
| Barcode | 6438177459330 |
| Packed Quantity | 1 |
| Height | 403mm |
| Width | 128mm |
| Depth | 233mm |
| HS Code | 85044085 |
| Amperage | 7.2A |
| Number of analogue inputs | 2 |
| Number of analogue outputs | 2 |
| Control Setting | CAN, DeviceNet, DeviceNet Safety, EtherNet/IP, Modbus, PROFIBUS, PROFINET IO, TCP/IP |
| Number of digital inputs | 6 |
| Number of digital outputs | 3 |
| Input Phases | Single Phase |
| Input Frequency | 50/60Hz |
| Integrated breaking resistance | Yes |
| Degree of protection (IP) | IP55 |
| KW Rating | 3kW |
| Number of HW-interfaces RS-485 | 1 |
| Number of HW-interfaces USB | 1 |
| Number of HW-interfaces parallel | 2 |
| Number of HW-interfaces other | 2 |
| Output Frequency | 500Hz |
| Output Voltage | 480VAC |
| Output Phases | Three phase |
| Type of Converter | U converter |
| Relative symmetric net frequency tolerance | 5% |
| Relative symmetric net voltage tolerance | 10% |
| Voltage | 380/480VAC |
| VSD Range | ABB ACS580 |
| Manufacturer | ABB |
| Country of Manufacture | Romania |
| Alternative Product SKU | 3AXD50000038968 |
