ACS380-042C-05A6-4 ABB 2.2kW Three Phase ABB ACS380 Variable Speed Drive

Why Choose the ABB ACS-AP-S Standard Assistant Control Panel?

The ABB 3AXD50000031865, commonly referred to as the ACS-AP-S Standard Assistant Control Panel, is an intuitive user interface designed for monitoring, configuring and commissioning ABB variable speed drives. It provides a clear display and menu-driven navigation that allows engineers to quickly access drive parameters, operational data and diagnostic information.

Developed as part of ABB’s all-compatible drive ecosystem, the ACS-AP-S panel offers a consistent interface across multiple drive platforms. Its simple keypad operation and structured parameter menus help simplify drive commissioning, daily operation and maintenance tasks in industrial automation systems.

The panel can be mounted directly onto compatible ABB drives or installed remotely on a control cabinet door using mounting accessories. This flexibility makes it suitable for both machine-level integration and centralised control panel installations within industrial environments.

Key Advantages

• Provides intuitive menu-driven configuration and monitoring for ABB drives.
• Simplifies drive commissioning and parameter setup.
• Enables quick access to fault diagnostics and operational status.
• Compatible with multiple ABB all-compatible drive families.
• Improves maintenance efficiency through clear drive information.
• Compact and robust design suitable for industrial environments.

Key Features

• Assistant control panel for ABB variable speed drives.
• LCD display for monitoring drive status and parameters.
• Keypad navigation with soft keys and arrow keys.
• Menu-based interface for parameter configuration and diagnostics.
• Supports drive commissioning, monitoring and troubleshooting.
• Compatible with ABB all-compatible drive platforms.
• Direct drive mounting or remote cabinet installation.

Technical Specifications

• Manufacturer: ABB
• Product number: 3AXD50000031865
• Model: ACS-AP-S
• Product type: Assistant control panel
• Display: LCD user interface
• Navigation: Keypad with soft keys and arrow buttons
• Functions: Drive monitoring, parameter configuration and diagnostics
• Compatibility: ABB all-compatible drives
• Typical supported drives: ACS380, ACS480, ACS580 and ACS880
• Mounting options: Direct drive mounting or cabinet door mounting kit
• Dimensions (approx.): 132 × 80 × 30 mm
• Weight: approx. 0.1 kg
• Application: Industrial drive monitoring and configuration

Drive Configuration and Monitoring

Efficient drive operation requires clear access to parameters, diagnostics and system information. Assistant control panels provide operators with a simple interface for interacting with variable speed drives, reducing commissioning time and simplifying maintenance procedures.

The ABB ACS-AP-S panel offers intuitive navigation and clear operational feedback. Engineers can easily configure drive parameters, monitor motor performance and access troubleshooting data directly from the panel interface, improving system reliability and service efficiency.

Typical Applications

• Commissioning and configuration of ABB variable speed drives.
• Monitoring drive status in industrial automation systems.
• Machine control cabinets using ABB drive technology.
• Maintenance and diagnostics of motor control installations.
• Industrial production equipment requiring drive monitoring.

Trusted by Drive Engineers

ABB assistant control panels are widely trusted by automation engineers and maintenance teams to simplify commissioning, monitoring and maintenance of industrial drive systems.
