36108 Wohner hybrid motor starter, 3-pole
MPN: 36108
Alt. SKU: 36108000B
Special Price
£295.12
£245.93
Regular Price
£368.89
Why Choose the Hybrid Motor Starter, 3-pole (36108)?
The MOTUS 60Classic hybrid motor starter offers a compact and efficient solution for motor control applications. Integrating four essential functions—right contactor, left contactor, motor protection relay, and EMERGENCY STOP protection up to category 3—this device ensures reliable operation and enhanced safety. Its slim design with an installed width of only 22.5mm makes it ideal for space-saving installations. Featuring CrossLink® Technology, it supports direct and reversing starter functions with rated currents up to 6.5 A, suitable for various busbar sizes. Certified with multiple international approvals, it guarantees compliance and quality for demanding industrial environments.
Key Benefits
- Four integrated functions in one compact unit, reducing wiring and installation time.
- Supports direct and reversing motor starting with rated currents from 1.5 to 6.5 A.
- Switches resistive loads up to 9.0 A, providing versatile application options.
- Compatible with busbars of various sizes: 12, 15, 20, 25, 30 x 5, 10 mm and section busbars.
- CrossLink® Technology enhances performance and reliability.
- EMERGENCY STOP protection up to category 3 for increased safety compliance.
- Extremely durable with 30 million electrical switching operations.
- Halogen-free construction supports environmentally responsible installations.
- Multiple international approvals including UL, CCC, and ATEX ensure global compliance.
Technical Specifications
- Item number: 36108
- Description: hybrid motor starter, 3-pole
- Rated current: 6.5 A
- Rated voltage AC: 500 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 22.5 x 200 x 156 mm
- Weight: 56.6 kg/100
- Halogen free: Yes
- Approval: UL 60947-1
- Approval: UL , CCC , Atex
- Approval: for UL feeder circuits >250V
- Approval: type number: 36111.1
- Approval: UL file: E360470, UL category (for USA): NLDX https://www.ul.com
- Approval: UL file: E360470, UL category (for Canada): NLDX7 https://www.ul.com
- Approval: CCC certificate: 2019010304252617
- Approval: Type-Examination Certificate: PTB13AT3001
Frequently Asked Questions
What functions are integrated in the hybrid motor starter?
The starter integrates four functions: right contactor, left contactor, motor protection relay, and EMERGENCY STOP protection up to category 3.
Is this motor starter suitable for reversing motor applications?
Yes, it supports both direct and reversing motor starting with rated currents from 1.5 to 6.5 A.
What busbar sizes are compatible with this product?
It is compatible with busbars sized 12, 15, 20, 25, 30 x 5, 10 mm as well as section busbars.
Does this product carry current mechanically?
This is an electrical device designed for switching and motor protection; mechanical parts do not carry current.
What certifications does the hybrid motor starter have?
It holds UL 60947-1, UL, CCC, ATEX approvals, and specific UL files for USA and Canada, as well as a CCC certificate and Type-Examination Certificate.
| Manufacturer Part Number | 36108 |
|---|---|
| Barcode | 4021267361082 |
| Height | 200mm |
| Width | 22.5mm |
| Depth | 156mm |
| Alternative Product SKU | 36108000B |
| Manufacturer | Wohner |
| Packed Quantity | 1 |
| Degree of protection (IP) | IP20 |
| Type of electrical connection of main circuit | Other |
| Rated operation current Ie | 9A |
