32454 Wohner busbar adapter 63 A
MPN: 32454
Alt. SKU: 32454000
Special Price
£26.22
£21.85
Regular Price
£32.78
Why Choose the Busbar Adapter 63 A (32454)?
The busbar adapter 63 A (Part No.: 32454 000) is designed for seamless integration with EQUES 60Classic systems, offering a reliable and efficient solution for electrical distribution. Its adjustable mounting rail and compatibility with various busbar sizes ensure versatile application. The ultrasonically sealed conductor ends and secure click mechanism provide enhanced safety and ease of installation. This adapter is halogen free, supporting environmentally conscious installations.
Key Benefits
- Rated current capacity of 65 A suitable for demanding electrical loads.
- Compatible with busbars of sizes 12, 15, 20, 25, 30 x 5, 10 mm and section busbars.
- Ultrasonically sealed conductor ends ensure superior electrical connection and durability.
- Click mechanism enables quick and secure mounting onto busbars.
- Adjustable mounting rail for flexible installation options.
- Halogen free construction supports safer and environmentally friendly installations.
- Comprehensive approvals including UL 508, CSA, UL, and DNV GL for assured quality and compliance.
Technical Specifications
- Item number: 32454
- Description: busbar adapter 63 A
- Rated current: 65 A
- Rated voltage AC: 600 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 54 x 200 x 63 mm
- Weight: 39.2 kg/100
- Halogen free: Yes
- Approval: UL 508
- Approval: CSA , UL , DNV GL
- Approval: for UL feeder circuits >250V
- Approval: type number: EEC6063-L
- Approval: UL file: E123577, UL category (for USA): NMTR https://www.ul.com
- Approval: UL file: E123577, UL category (for Canada): NMTR7 https://www.ul.com
- Approval: CSA file: 110285, CSA class: 3211-37 https://directories.csa-international.org
- Approval: CCC approval: no certification required
Frequently Asked Questions
What busbar sizes are compatible with this adapter?
This busbar adapter is compatible with busbars sized 12, 15, 20, 25, 30 x 5, 10 mm as well as section busbars.
Does this adapter carry current directly?
As a mechanical adapter, it does not carry current itself but facilitates secure and reliable connections between busbars and electrical components.
Is the busbar adapter suitable for use in halogen-free installations?
Yes, the busbar adapter is halogen free, making it suitable for installations requiring halogen-free components.
What approvals does this product have?
The adapter holds multiple approvals including UL 508, CSA, UL, and DNV GL, ensuring compliance with international safety standards.
Where can I find technical documentation for installation?
Mounting instructions and technical information are available for download from the manufacturer's website.
| Manufacturer Part Number | 32454 |
|---|---|
| Barcode | 4021267324544 |
| Height | 200mm |
| Width | 54mm |
| Depth | 63mm |
| Alternative Product SKU | 32454000 |
| Manufacturer | Wohner |
| Packed Quantity | 4 |
