32453 Wohner busbar adapter 32 A
MPN: 32453
Alt. SKU: 32453000
Special Price
£55.33
£46.11
Regular Price
£69.17
Why Choose the Busbar Adapter 32 A (32453)?
The busbar adapter 32 A (Part No.: 32453 000) is designed for seamless integration with reversing starters Eaton PKZM0 and PKE32, ensuring reliable and efficient electrical connections. With its ultrasonic sealed conductor ends and a secure click mechanism for easy attachment to busbars, this adapter guarantees a stable and durable connection. Its compatibility with various busbar sizes and sections makes it a versatile choice for your electrical distribution needs.
Key Benefits
- Compatible with busbars 12, 15, 20, 25, 30 x 5, 10 mm and section busbars
- Ultrasonically sealed conductor ends for enhanced durability and conductivity
- Click mechanism ensures secure and easy installation onto busbars
- Halogen-free construction supports environmentally friendly installations
- Approved by UL, CSA, and DNV GL for reliable and safe operation
- Suitable for UL feeder circuits above 250 V
- Mechanical product – does not carry current itself but facilitates secure electrical connections
Technical Specifications
- Item number: 32453
- Description: busbar adapter 32 A
- Rated current: 25 A
- Rated voltage AC: 600 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 90 x 200 x 63 mm
- Weight: 61.2 kg/100
- Halogen free: Yes
- Approval: UL 508
- Approval: CSA , UL , DNV GL
- Approval: for UL feeder circuits >250V
- Approval: type number: EEC6025-L
- Approval: UL file: E123577, UL category (for USA): NMTR https://www.ul.com
- Approval: UL file: E123577, UL category (for Canada): NMTR7 https://www.ul.com
- Approval: CSA file: 110285, CSA class: 3211-37 https://directories.csa-international.org
- Approval: CCC approval: no certification required
Frequently Asked Questions
What busbar sizes are compatible with this adapter?
The adapter is compatible with busbars sized 12, 15, 20, 25, 30 x 5, 10 mm as well as section busbars.
Does this adapter carry electrical current?
This is a mechanical adapter designed to facilitate connections; it does not carry current itself.
Is the product environmentally friendly?
Yes, the busbar adapter is halogen-free, supporting safer and more environmentally responsible installations.
What approvals does this product have?
It holds UL 508, CSA, UL, and DNV GL approvals and is suitable for UL feeder circuits above 250 V.
Where can I find technical documents and CAD models?
Technical information, mounting instructions, and CAD models in various formats are available via the provided download links on the product page.
| Manufacturer Part Number | 32453 |
|---|---|
| Barcode | 4021267324537 |
| Height | 200mm |
| Width | 90mm |
| Depth | 63mm |
| Alternative Product SKU | 32453000 |
| Manufacturer | Wohner |
| Packed Quantity | 2 |
