32446 Wohner busbar adapter 32 A
MPN: 32446
Alt. SKU: 32446000
Special Price
£43.70
£36.42
Regular Price
£54.64
Why Choose the Busbar Adapter 32 A (32446)?
The busbar adapter 32 A (part number 32446) is designed to provide a reliable and efficient connection solution for busbars in electrical installations. Featuring two adjustable mounting rails and compatibility with various busbar sizes, this adapter ensures flexibility and ease of installation. Its conductor ends are ultrasonically sealed, guaranteeing a secure and durable connection. The click mechanism allows for effortless attachment to the busbar, enhancing installation speed and safety. Additionally, the adapter is halogen-free, supporting environmentally conscious projects.
Key Benefits
- Supports busbars of multiple dimensions: 12, 15, 20, 25, 30 x 5, 10 mm and section busbars
- Two adjustable mounting rails for versatile installation options
- Ultrasonically sealed conductor ends for enhanced connection reliability
- Click mechanism ensures secure and quick mounting onto busbars
- Halogen-free material for safer and eco-friendly applications
- Complies with major approvals including UL 508, CSA, and DNV GL
- Suitable for UL feeder circuits above 250 V
Technical Specifications
- Item number: 32446
- Description: busbar adapter 32 A
- Rated current: 30 A
- Rated voltage AC: 600 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 81 x 200 x 63 mm
- Weight: 49.5 kg/100
- Halogen free: Yes
- Approval: UL 508
- Approval: CSA , UL , DNV GL
- Approval: for UL feeder circuits >250V
- Approval: type number: EEC6032-L
- Approval: UL file: E123577, UL category (for USA): NMTR https://www.ul.com
- Approval: UL file: E123577, UL category (for Canada): NMTR7 https://www.ul.com
- Approval: CSA file: 110285, CSA class: 3211-37 https://directories.csa-international.org
- Approval: CCC approval: no certification required
Frequently Asked Questions
What busbar sizes are compatible with this adapter?
The busbar adapter supports busbars sized 12, 15, 20, 25, 30 x 5, 10 mm as well as section busbars.
Is this adapter suitable for high current applications?
The adapter is rated for a current of 30 A and is designed for use within these electrical limits.
Does this product carry current directly?
This busbar adapter is an electrical component designed to connect busbars and conduct current safely within its rated specifications.
What approvals does this product have?
It holds UL 508, CSA, UL, and DNV GL approvals and is suitable for UL feeder circuits above 250 V.
Is the material halogen-free?
Yes, the busbar adapter is made from halogen-free materials.
| Manufacturer Part Number | 32446 |
|---|---|
| Barcode | 4021267324469 |
| Height | 200mm |
| Width | 81mm |
| Depth | 63mm |
| Alternative Product SKU | 32446000 |
| Manufacturer | Wohner |
| Packed Quantity | 4 |
