31397 Wohner holder for cylindrical fuses, with LED

Why Choose the Eaton Cylindrical Fuse Link 3 A (31397)?

The Eaton Cylindrical Fuse Link 3 A (31397) is a reliable and high-quality component designed for control transformer applications. With a robust porcelain construction and halogen-free materials, this fuse link ensures safety and environmental compliance. Its time delay operation and Class CC rating make it ideal for protecting circuits from transient surges without unnecessary interruptions. Certified to stringent UL and CSA standards, it guarantees dependable performance in demanding electrical environments.

Key Benefits

• Time Delay Operation: Allows temporary current surges without blowing, protecting sensitive equipment.
• High Voltage Rating: Suitable for use up to 600 V AC, accommodating a wide range of industrial applications.
• Compact Dimensions: Measures 10 x 10 x 38 mm, fitting easily into existing fuse holders.
• Durable Porcelain Material: Offers excellent insulation and mechanical strength.
• Halogen-Free: Environmentally friendly design reduces toxic emissions in case of fire.
• Certified Safety: Complies with UL 248-1, UL 248-4, and CSA standards for assured reliability.

Technical Specifications

• Item number: 31397
• Description: cylindr. fuse link 3 A
• Rated current: 3 A
• Rated voltage AC: 600 V
• Rated frequency: 50 / 60 Hz
• Dimensions (W x H x D): 10 x 10 x 38 mm
• Weight: 0.8 kg/100
• Material: Porcelain
• Halogen free: Yes
• Approval: UL 248-1
• Approval: UL 248-4
• Approval: CSA , UL
• Approval: type number: FNQ-R
• Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
• Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
