31396 Wohner holder for cylindrical fuses, with LED
MPN: 31396
Alt. SKU: 31396000
Special Price
£21.67
£18.06
Regular Price
£27.08
Why Choose the Eaton Cylindrical Fuse Link 2.5 A (31396)?
The Eaton Cylindrical Fuse Link 2.5 A is a reliable and high-quality component designed specifically for control transformer applications. Featuring a time delay operation and Class CC rating, it ensures optimal protection for electrical circuits operating at up to 600 V AC. Manufactured with durable porcelain material and halogen-free composition, this fuse link meets stringent safety and environmental standards. Its approvals from UL and CSA further guarantee compliance with international safety regulations.
Key Benefits
- Time delay operation protects against transient overloads while preventing nuisance tripping.
- Class CC rating provides compact size with high interrupting capacity for enhanced safety.
- Porcelain construction ensures mechanical robustness and excellent insulation properties.
- Halogen-free design supports environmentally responsible installations.
- Certified by UL and CSA, ensuring compliance with North American safety standards.
- Ideal for use in control transformer circuits, providing reliable overcurrent protection.
Technical Specifications
- Item number: 31396
- Description: cylindr. fuse link 2,5 A
- Rated current: 2.5 A
- Rated voltage AC: 600 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 10 x 10 x 38 mm
- Weight: 0.8 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-1
- Approval: UL 248-4
- Approval: CSA , UL
- Approval: type number: FNQ-R
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What is the purpose of this fuse link?
This fuse link is designed to protect control transformers and associated circuits by interrupting overcurrent conditions safely.
Does this fuse link carry current continuously?
Yes, as an electrical fuse link, it carries current under normal operating conditions and interrupts current only during fault conditions.
What does time delay mean in this fuse?
Time delay means the fuse can tolerate temporary current surges without blowing, which is useful for devices with transient start-up currents.
Is this fuse link environmentally friendly?
Yes, it is halogen-free, reducing harmful emissions in case of fire and supporting eco-friendly installations.
What certifications does this fuse link have?
It holds UL 248-1, UL 248-4, and CSA approvals, ensuring compliance with North American safety standards.
| Manufacturer Part Number | 31396 |
|---|---|
| Barcode | 4021267313968 |
| Height | 10mm |
| Width | 10mm |
| Depth | 38mm |
| Alternative Product SKU | 31396000 |
| Manufacturer | Wohner |
| Packed Quantity | 10 |
