31395 Wohner holder for cylindrical fuses, with LED
MPN: 31395
Alt. SKU: 31395000
Special Price
£21.67
£18.06
Regular Price
£27.08
Why Choose the Eaton Cylindrical Fuse Link 1.5 A (31395)?
The Eaton Cylindrical Fuse Link 1.5 A (Part No. 31395) is a reliable and high-quality electrical protection device designed for control transformer applications. Featuring a time delay operation and Class CC rating, it ensures optimal protection for your electrical systems. Manufactured with durable porcelain material and halogen-free construction, this fuse link complies with stringent safety standards and approvals including UL and CSA certifications. Its compact dimensions and robust design make it an ideal choice for industrial and commercial electrical installations.
Key Benefits
- Time delay operation provides protection against temporary overloads without nuisance blowing.
- Class CC rating ensures fast and reliable interruption of overcurrents.
- Suitable for control transformer applications, enhancing system safety and longevity.
- Constructed from porcelain, offering excellent insulation and mechanical strength.
- Halogen-free materials promote environmental safety and reduce toxic emissions in case of fire.
- Complies with multiple approvals including UL 248-1, UL 248-4, and CSA for assured quality and performance.
- Compact size (10 x 10 x 38 mm) facilitates easy installation in tight spaces.
Technical Specifications
- Item number: 31395
- Description: cylindr. fuse link 1,5 A
- Rated current: 1.5 A
- Rated voltage AC: 600 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 10 x 10 x 38 mm
- Weight: 0.8 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-1
- Approval: UL 248-4
- Approval: CSA , UL
- Approval: type number: FNQ-R
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What is the primary application of this fuse link?
This fuse link is primarily designed for control transformer applications, providing reliable overcurrent protection.
Does the fuse link carry current continuously?
Yes, as an electrical fuse link, it carries current under normal operating conditions and interrupts the circuit when overcurrent occurs.
What does the time delay operation mean?
Time delay operation allows the fuse to withstand temporary current surges without blowing, preventing unnecessary interruptions.
Is this fuse link environmentally friendly?
Yes, it is made from halogen-free materials, reducing harmful emissions in the event of fire.
What approvals does this product have?
The fuse link is approved under UL 248-1, UL 248-4, CSA, and carries specific UL and CSA file numbers ensuring compliance with safety standards.
| Manufacturer Part Number | 31395 |
|---|---|
| Barcode | 4021267313951 |
| Height | 10mm |
| Width | 10mm |
| Depth | 38mm |
| Alternative Product SKU | 31395000 |
| Manufacturer | Wohner |
| Packed Quantity | 10 |
