Fuse Link 60 A (31364) by Eaton

The Eaton fuse link 60 A (Part No.: 31364 100) is a high-quality, time delay fuse designed for reliable protection in electrical circuits. Rated for 600 V AC and 300 V DC, this Class J fuse link ensures superior performance and safety in demanding industrial applications.

Why Choose the Eaton Fuse Link 60 A?

• Time delay operation for protection against transient overloads without nuisance blowing.
• High interrupting rating with 300 kA AC and 100 kA DC short-circuit current rating (SCCR).
• Constructed from durable porcelain material, ensuring long-lasting performance and safety.
• Halogen-free design supporting environmentally responsible installations.
• Comprehensive approvals including UL 248-8, UL 248-1, and CSA certification for assured quality and compliance.

Key Benefits

• Reliable circuit protection for industrial and commercial electrical systems.
• Time delay feature allows temporary overloads without fuse failure, enhancing system uptime.
• Compact dimensions (27 x 60 x 27 mm) for easy integration into existing fuse holders.
• Suitable for use in both AC and DC circuits with rated voltages of 600 V AC and 300 V DC.
• Lightweight design at 8.5 kg per 100 units facilitates handling and installation.

Technical Specifications

• Item number: 31364
• Description: fuse link 60 A
• Rated current: 60 A
• Rated voltage AC: 600 V
• Rated voltage DC: 300 V
• Rated frequency: 50 / 60 Hz
• Dimensions (W x H x D): 27 x 60 x 27 mm
• Weight: 8.5 kg/100
• Material: Porcelain
• Halogen free: Yes
• Approval: UL 248-8
• Approval: UL 248-1
• Approval: CSA , UL
• Approval: type number: LPJ
• Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
• Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
