Fuse Link 50 A (31363) by Eaton

Ensure reliable circuit protection with the Eaton fuse link 50 A, designed for high performance and safety in electrical installations. This Class J time delay fuse link is ideal for applications requiring dependable overload and short-circuit protection.

Why Choose the Eaton Fuse Link 50 A?

• High interrupting capacity with 300 kA AC and 100 kA DC ratings for superior safety.
• Time delay operation to prevent nuisance blowing from temporary surges.
• Constructed from durable porcelain material that is halogen free, ensuring environmental safety.
• Certified to UL 248-8, UL 248-1, and CSA standards for assured quality and compliance.
• Compact dimensions (27 x 60 x 27 mm) suitable for various electrical panels and equipment.

Key Benefits

• Reliable protection for circuits up to 50 A and 600 V AC, with DC rating of 300 V.
• Time delay feature allows temporary current surges without fuse interruption, enhancing system uptime.
• Lightweight design (8.5 kg per 100 units) facilitates easy handling and installation.
• Halogen-free construction supports safer disposal and reduces environmental impact.
• Wide approval range ensures compatibility and acceptance in multiple regions and industries.

Technical Specifications

• Item number: 31363
• Description: fuse link 50 A
• Rated current: 50 A
• Rated voltage AC: 600 V
• Rated voltage DC: 300 V
• Rated frequency: 50 / 60 Hz
• Dimensions (W x H x D): 27 x 60 x 27 mm
• Weight: 8.5 kg/100
• Material: Porcelain
• Halogen free: Yes
• Approval: UL 248-8
• Approval: UL 248-1
• Approval: CSA , UL
• Approval: type number: LPJ
• Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
• Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
