31362 Wohner holder for cylindrical fuses, for semiconductor fuses
MPN: 31362
Alt. SKU: 31362000
Special Price
£56.84
£47.37
Regular Price
£71.05
Why Choose the Eaton Fuse Link 45 A (31362)?
The Eaton fuse link 45 A (part number 31362) is a reliable and high-performance electrical protection device designed to safeguard your circuits. With a time delay operation and Class J rating, it offers superior protection for industrial and commercial applications. Manufactured from durable porcelain and halogen-free materials, this fuse link ensures safety and environmental compliance. It is UL and CSA approved, meeting stringent safety standards for peace of mind.
Key Benefits
- Rated for 45 A current and 600 V AC, suitable for a wide range of electrical systems.
- Time delay operation allows temporary current surges without nuisance blowing.
- Compact dimensions (27 x 60 x 27 mm) for easy installation in fuse holders.
- Constructed from porcelain, a non-conductive material that does not carry current itself, ensuring safe operation.
- Halogen-free design reduces environmental impact and enhances safety in case of fire.
- High short-circuit current rating (SCCR) of 300 kA AC and 100 kA DC for robust protection.
- Certified to UL 248-8, UL 248-1, and CSA standards, guaranteeing compliance with international safety requirements.
Technical Specifications
- Item number: 31362
- Description: fuse link 45 A
- Rated current: 45 A
- Rated voltage AC: 600 V
- Rated voltage DC: 300 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 27 x 60 x 27 mm
- Weight: 8.5 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-8
- Approval: UL 248-1
- Approval: CSA , UL
- Approval: type number: LPJ
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What is the purpose of the time delay feature?
The time delay feature allows the fuse link to withstand temporary current surges without blowing, which is useful for protecting motors and other equipment that have high inrush currents.
Is the fuse link suitable for DC applications?
Yes, the fuse link is rated for 300 V DC, making it suitable for certain DC electrical systems within this voltage limit.
Does the porcelain material carry current?
No, porcelain is an insulating material used for the fuse body and does not carry current. It provides mechanical strength and electrical insulation.
Where can I find technical documentation?
Technical information, characteristics, and EU declaration of conformity can be downloaded from the manufacturer's website.
| Manufacturer Part Number | 31362 |
|---|---|
| Barcode | 4021267313623 |
| Height | 60mm |
| Width | 27mm |
| Depth | 27mm |
| Alternative Product SKU | 31362000 |
| Manufacturer | Wohner |
| Packed Quantity | 10 |
