31361 Wohner holder for cylindrical fuses, for semiconductor fuses
MPN: 31361
Alt. SKU: 31361000
Special Price
£56.84
£47.37
Regular Price
£71.05
Fuse Link 40 A (31361) by Eaton
The Eaton fuse link 40 A (part number 31361) is a high-quality, time delay fuse designed for reliable circuit protection. Rated for 600 V AC and 300 V DC, it is suitable for a wide range of industrial electrical applications. Constructed from durable porcelain and halogen free materials, this Class J fuse link ensures safety and compliance with international standards.
Why Choose the Eaton Fuse Link 40 A?
- Reliable Protection: Time delay operation allows temporary current surges without nuisance blowing, protecting sensitive equipment effectively.
- High Safety Standards: Certified to UL 248-8, UL 248-1, and CSA standards, ensuring compliance and safety in demanding environments.
- Robust Construction: Made from porcelain, the fuse link is durable and halogen free, supporting environmentally responsible installations.
- Wide Voltage Compatibility: Suitable for use up to 600 V AC and 300 V DC, making it versatile for various electrical systems.
Key Benefits
- Class J fuse link providing high interrupting capacity and compact size.
- Time delay feature protects against transient overloads without unnecessary interruptions.
- Lightweight design with 8.5 kg per 100 units, facilitating easy handling and installation.
- Comprehensive approvals including UL and CSA for trusted performance.
- Halogen free materials contribute to safer and greener electrical installations.
Technical Specifications
- Item number: 31361
- Description: fuse link 40 A
- Rated current: 40 A
- Rated voltage AC: 600 V
- Rated voltage DC: 300 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 27 x 60 x 27 mm
- Weight: 8.5 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-8
- Approval: UL 248-1
- Approval: CSA , UL
- Approval: type number: LPJ
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What is the primary function of this fuse link?
This fuse link provides overcurrent protection by interrupting excessive current flow, preventing damage to electrical circuits and equipment.
Does the fuse link carry current continuously?
Yes, the fuse link is designed to carry current under normal operating conditions and will interrupt the circuit only when the current exceeds its rated capacity.
What does time delay mean in this fuse link?
Time delay means the fuse can tolerate short-term current surges without blowing, which is ideal for circuits with temporary inrush currents.
Is this fuse link suitable for DC applications?
Yes, it is rated for use up to 300 V DC, making it suitable for both AC and DC circuits within specified limits.
Is the fuse link environmentally friendly?
Yes, it is made from halogen free materials, supporting safer and more environmentally responsible installations.
| Manufacturer Part Number | 31361 |
|---|---|
| Barcode | 4021267313616 |
| Height | 60mm |
| Width | 27mm |
| Depth | 27mm |
| Alternative Product SKU | 31361000 |
| Manufacturer | Wohner |
| Packed Quantity | 10 |
