31360 Wohner holder for cylindrical fuses, for semiconductor fuses
MPN: 31360
Alt. SKU: 31360000
Special Price
£56.84
£47.37
Regular Price
£71.05
Why Choose the Eaton Fuse Link 35 A (31360)?
The Eaton fuse link 35 A (part number 31360) is a reliable and high-quality electrical protection component designed to safeguard your electrical systems. Rated for 600 V AC and 300 V DC, this time delay fuse link offers excellent protection against overloads and short circuits. Manufactured with durable porcelain material and halogen-free construction, it ensures safety and environmental compliance. Certified to stringent UL and CSA standards, it is ideal for industrial and commercial applications requiring dependable circuit protection.
Key Benefits
- Time delay operation for protection against transient overloads
- High interrupting rating: 300 kA AC and 100 kA DC for enhanced safety
- Robust porcelain construction ensures durability and electrical insulation
- Halogen-free materials support environmentally friendly installations
- Comprehensive approvals including UL 248-8, UL 248-1, and CSA for assured quality
- Compact dimensions (27 x 60 x 27 mm) suitable for space-constrained panels
Technical Specifications
- Item number: 31360
- Description: fuse link 35 A
- Rated current: 35 A
- Rated voltage AC: 600 V
- Rated voltage DC: 300 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 27 x 60 x 27 mm
- Weight: 8.5 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-8
- Approval: UL 248-1
- Approval: CSA , UL
- Approval: type number: LPJ
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What is the purpose of this fuse link?
This fuse link is designed to protect electrical circuits by interrupting current flow in the event of an overload or short circuit, preventing damage to equipment and enhancing safety.
Does this fuse link carry current continuously?
Yes, the fuse link carries current under normal operating conditions up to its rated current of 35 A. It is designed to interrupt current only when an overcurrent condition occurs.
Is the fuse link suitable for both AC and DC applications?
Yes, it is rated for use in AC circuits up to 600 V and DC circuits up to 300 V, making it versatile for various electrical systems.
What does time delay mean in this fuse link?
Time delay means the fuse can tolerate temporary current surges without blowing immediately, which is useful in applications with transient inrush currents such as motors or transformers.
Is the fuse link environmentally friendly?
Yes, the fuse link is halogen-free, reducing harmful emissions in case of fire and supporting environmentally responsible installations.
| Manufacturer Part Number | 31360 |
|---|---|
| Barcode | 4021267313609 |
| Height | 60mm |
| Width | 27mm |
| Depth | 27mm |
| Alternative Product SKU | 31360000 |
| Manufacturer | Wohner |
| Packed Quantity | 10 |
