31359 Wohner holder for cylindrical fuses, for semiconductor fuses
MPN: 31359
Alt. SKU: 31359000
Special Price
£29.30
£24.42
Regular Price
£36.64
Why Choose the Eaton Fuse Link 30 A (31359)?
The Eaton fuse link 30 A (Part No. 31359) is designed for reliable circuit protection in industrial and commercial electrical systems. Featuring a time delay operation and Class J rating, this fuse link ensures excellent performance under transient overload conditions. Its porcelain construction is halogen-free, promoting safety and environmental responsibility. Certified by UL and CSA, it meets rigorous safety standards for use in demanding applications up to 600 V AC and 300 V DC.
Key Benefits
- Time Delay Operation: Provides protection against temporary overloads without nuisance blowing.
- High Interrupting Capacity: Rated for 300 kA AC and 100 kA DC short circuit current ratings, ensuring robust safety.
- Durable Construction: Made from porcelain, offering excellent mechanical strength and thermal resistance.
- Halogen-Free: Environmentally friendly material reduces toxic emissions in case of fire.
- Wide Voltage Compatibility: Suitable for systems up to 600 V AC and 300 V DC.
- Certified Quality: Meets UL 248-8, UL 248-1, and CSA standards for assured reliability.
Technical Specifications
- Item number: 31359
- Description: fuse link 30 A
- Rated current: 30 A
- Rated voltage AC: 600 V
- Rated voltage DC: 300 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 21 x 57 x 21 mm
- Weight: 5.0 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-8
- Approval: UL 248-1
- Approval: CSA , UL
- Approval: type number: LPJ
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What is the purpose of a fuse link?
A fuse link is designed to protect electrical circuits by breaking the circuit if the current exceeds a safe level, preventing damage to equipment and reducing fire risk.
Does this fuse link carry current continuously?
Yes, the fuse link carries current under normal operating conditions but will interrupt the circuit if an overload or short circuit occurs.
What does 'time delay' mean in this fuse link?
Time delay means the fuse can withstand temporary current surges without blowing, which is useful for equipment with high inrush currents.
Is the fuse link environmentally friendly?
Yes, it is made from halogen-free porcelain, reducing harmful emissions in case of fire.
What approvals does this fuse link have?
It is approved by UL (UL 248-8, UL 248-1) and CSA, ensuring compliance with North American safety standards.
| Manufacturer Part Number | 31359 |
|---|---|
| Barcode | 4021267313593 |
| Height | 57mm |
| Width | 21mm |
| Depth | 21mm |
| Alternative Product SKU | 31359000 |
| Manufacturer | Wohner |
| Packed Quantity | 10 |
