31345 Wohner cylindr. fuse link 25 A
MPN: 31345
Alt. SKU: 31345000
Special Price
£29.30
£24.42
Regular Price
£36.64
Why Choose the Eaton Fuse Link 4 A (31345)?
The Eaton fuse link 4 A (part number 31345) is a reliable and high-quality electrical protection component designed for demanding industrial applications. Its time delay feature ensures selective tripping, preventing nuisance interruptions and protecting sensitive equipment. Rated for 600 V AC and 300 V DC, this Class J fuse link offers excellent performance and safety compliance, making it an essential choice for safeguarding electrical circuits.
Key Benefits
- Time Delay Operation: Allows temporary overloads without blowing, ensuring continuity of service and protection against short circuits.
- High Interrupting Capacity: Rated at 300 kA AC and 100 kA DC, providing superior fault current interruption capability.
- Robust Construction: Made from durable porcelain material that is halogen free, enhancing safety and environmental compliance.
- Wide Voltage Compatibility: Suitable for use in systems up to 600 V AC and 300 V DC.
- Certified and Approved: Meets UL 248-8, UL 248-1, and CSA standards, ensuring trusted performance and regulatory compliance.
Technical Specifications
- Item number: 31345
- Description: fuse link 4 A
- Rated current: 4 A
- Rated voltage AC: 600 V
- Rated voltage DC: 300 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 21 x 57 x 21 mm
- Weight: 5.0 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-8
- Approval: UL 248-1
- Approval: CSA , UL
- Approval: type number: LPJ
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What is the primary function of this fuse link?
The fuse link provides overcurrent protection by interrupting excessive current flow, preventing damage to electrical circuits and equipment.
Is this fuse link suitable for DC applications?
Yes, it is rated for up to 300 V DC, making it suitable for both AC and DC electrical systems.
Does the fuse link carry current continuously?
Yes, the fuse link is designed to carry current under normal operating conditions until a fault occurs.
What does the time delay operation mean?
Time delay allows the fuse to withstand temporary current surges without blowing, which is useful for protecting motors and other equipment with high inrush currents.
Is the fuse link environmentally friendly?
Yes, it is halogen free, reducing environmental impact and improving safety during use.
| Manufacturer Part Number | 31345 |
|---|---|
| Barcode | 4021267313456 |
| Height | 57mm |
| Width | 21mm |
| Depth | 21mm |
| Alternative Product SKU | 31345000 |
| Manufacturer | Wohner |
| Packed Quantity | 10 |
