31323 Wohner cylindr. fuse link 30 A
MPN: 31323
Alt. SKU: 31323000A
Special Price
£33.85
£28.21
Regular Price
£42.32
Why Choose the Eaton Fuse Link 10 A (31323)?
The Eaton Fuse Link 10 A (31323) is a reliable and fast-acting fuse link designed to protect electrical circuits operating at up to 600 V AC. Manufactured with high-quality porcelain material, it ensures durability and safety in demanding industrial environments. Its Class J rating and compliance with stringent UL and CSA standards guarantee superior performance and safety. This fuse link is halogen free, supporting environmentally responsible installations.
Key Benefits
- Fast acting fuse link for rapid circuit protection.
- Rated for 10 A current and 600 V AC voltage, suitable for a wide range of applications.
- Class J rating ensures high interrupting capacity and reliable operation.
- Constructed from durable porcelain material, providing excellent insulation and mechanical strength.
- Halogen free for safer and more eco-friendly installations.
- Certified with multiple approvals including UL 248-8, UL 248-1, and CSA for assured quality and compliance.
Technical Specifications
- Item number: 31323
- Description: fuse link 10 A
- Rated current: 10 A
- Rated voltage AC: 600 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 21 x 57 x 21 mm
- Weight: 5.0 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-8
- Approval: UL 248-1
- Approval: CSA , UL
- Approval: type number: JKS
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What type of fuse is the Eaton 31323?
It is a fast acting Class J fuse link designed for protecting electrical circuits up to 10 A and 600 V AC.
Is this fuse link suitable for high fault current applications?
Yes, it has a short-circuit current rating (SCCR) of 200 kA AC, making it suitable for high fault current conditions.
Does this fuse link carry current directly?
No, as a mechanical fuse link, it does not carry current continuously but interrupts the circuit when overcurrent occurs.
Is the Eaton 31323 fuse link environmentally friendly?
Yes, it is halogen free, contributing to safer and more environmentally responsible electrical installations.
| Manufacturer Part Number | 31323 |
|---|---|
| Barcode | 4021267313234 |
| Height | 57mm |
| Width | 21mm |
| Depth | 21mm |
| Alternative Product SKU | 31323000A |
| Manufacturer | Wohner |
| Packed Quantity | 10 |
| Utilization category according to IEC 60269 | Other |
| Release characteristic | J |
