31252 Wohner cylindr. fuse link 30 A
MPN: 31252
Alt. SKU: 31252000
Special Price
£21.67
£18.06
Regular Price
£27.08
Why Choose the Eaton Cylindr. Fuse Link 30 A (31252)?
The Eaton cylindr. fuse link 30 A (Part No. 31252) is designed for reliable protection in control transformer applications. With a robust porcelain construction and halogen-free materials, this Class CC time delay fuse link ensures safety and durability under demanding electrical conditions. Its 600 V AC rating and 30 A current capacity make it suitable for a wide range of industrial uses, while compliance with UL and CSA standards guarantees trusted performance.
Key Benefits
- Time delay operation for protection against transient overloads
- High interrupting rating with a short-circuit current rating (SCCR) of 200 kA
- Compact dimensions (10 x 10 x 38 mm) for easy integration into control panels
- Porcelain material ensures excellent insulation and mechanical strength
- Halogen-free construction supports environmentally responsible installations
- Multiple approvals including UL 248-1, UL 248-4, and CSA for assured quality and safety
- Specifically designed for control transformer applications
Technical Specifications
- Item number: 31252
- Description: cylindr. fuse link 30 A
- Rated current: 30 A
- Rated voltage AC: 600 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 10 x 10 x 38 mm
- Weight: 0.8 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-1
- Approval: UL 248-4
- Approval: CSA , UL
- Approval: type number: FNQ-R
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What applications is this fuse link suitable for?
This fuse link is specifically designed for control transformer applications, providing reliable protection against overloads and short circuits.
Does the fuse link carry current continuously?
Yes, as an electrical fuse link, it carries current during normal operation and interrupts the circuit when an overcurrent condition occurs.
Is the fuse link environmentally friendly?
Yes, it is made from halogen-free materials, supporting environmentally responsible installations.
What approvals does this fuse link have?
It holds multiple approvals including UL 248-1, UL 248-4, and CSA certification, ensuring compliance with safety standards.
| Manufacturer Part Number | 31252 |
|---|---|
| Barcode | 4021267312527 |
| Height | 10mm |
| Width | 10mm |
| Depth | 38mm |
| Alternative Product SKU | 31252000 |
| Manufacturer | Wohner |
| Packed Quantity | 10 |
