31250 Wohner cylindr. fuse link 20 A
MPN: 31250
Alt. SKU: 31250000
Special Price
£21.67
£18.06
Regular Price
£27.08
Why Choose the Eaton Cylindrical Fuse Link 20 A (31250)?
The Eaton Cylindrical Fuse Link 20 A is designed for reliable protection in control transformer applications. Featuring a time delay operation and Class CC rating, this fuse link ensures optimal performance under varying electrical loads. Its porcelain construction guarantees durability and safety, while being halogen free supports environmentally conscious installations. Certified to stringent UL and CSA standards, it provides peace of mind for industrial and commercial electrical systems.
Key Benefits
- Time delay operation protects against temporary overloads without nuisance tripping.
- Class CC rating offers compact size with high interrupting capacity.
- Porcelain material ensures robust mechanical strength and electrical insulation.
- Halogen free design reduces environmental impact and enhances safety.
- Approvals from UL and CSA confirm compliance with international safety standards.
- Suitable for 600 V AC and 300 V DC applications at 50/60 Hz frequency.
Technical Specifications
- Item number: 31250
- Description: cylindr. fuse link 20 A
- Rated current: 20 A
- Rated voltage AC: 600 V
- Rated voltage DC: 300 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 10 x 10 x 38 mm
- Weight: 0.8 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-1
- Approval: UL 248-4
- Approval: CSA , UL
- Approval: type number: FNQ-R
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What applications is this fuse link suitable for?
This fuse link is ideal for control transformer applications requiring time delay protection.
Does the fuse link carry current?
Yes, as an electrical fuse link, it is designed to carry current and protect circuits by interrupting excessive current flow.
Is the fuse link environmentally friendly?
Yes, it is halogen free, reducing harmful emissions in case of fire and supporting safer disposal.
What approvals does this fuse link have?
It is approved by UL and CSA, meeting rigorous safety and performance standards.
| Manufacturer Part Number | 31250 |
|---|---|
| Barcode | 4021267312503 |
| Height | 10mm |
| Width | 10mm |
| Depth | 38mm |
| Alternative Product SKU | 31250000 |
| Manufacturer | Wohner |
| Packed Quantity | 10 |
