31248 Wohner cylindr. fuse link 10 A
MPN: 31248
Alt. SKU: 31248000
Special Price
£21.67
£18.06
Regular Price
£27.08
Why Choose the Eaton Cylindrical Fuse Link 10 A (31248)?
The Eaton Cylindrical Fuse Link 10 A is a reliable and high-quality component designed for control transformer applications. With a time delay operation and Class CC rating, it offers excellent protection for your electrical systems. Manufactured from durable porcelain and halogen free, this fuse link ensures safety and environmental compliance. Its 600 V AC rating and 10 A current capacity make it suitable for a wide range of industrial electrical applications.
Key Benefits
- Time delay operation provides protection against temporary overloads without nuisance blowing.
- Class CC rating ensures compact size with high interrupting capacity.
- Constructed from porcelain for robust mechanical strength and insulation.
- Halogen free material supports environmentally friendly installations.
- Approvals from UL and CSA guarantee compliance with stringent safety standards.
- Ideal for control transformer applications, enhancing system reliability.
Technical Specifications
- Item number: 31248
- Description: cylindr. fuse link 10 A
- Rated current: 10 A
- Rated voltage AC: 600 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 10 x 10 x 38 mm
- Weight: 0.8 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-1
- Approval: UL 248-4
- Approval: CSA , UL
- Approval: type number: FNQ-R
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What applications is this fuse link suitable for?
This fuse link is designed primarily for control transformer applications, providing reliable protection against overloads and short circuits.
Does the fuse link carry current continuously?
Yes, the fuse link is designed to carry current continuously up to its rated current of 10 A under normal operating conditions.
Is the fuse link environmentally friendly?
Yes, it is made from halogen free materials, supporting environmentally responsible installations.
What approvals does this fuse link have?
It holds multiple approvals including UL 248-1, UL 248-4, and CSA certifications, ensuring compliance with international safety standards.
| Manufacturer Part Number | 31248 |
|---|---|
| Barcode | 4021267312480 |
| Height | 10mm |
| Width | 10mm |
| Depth | 38mm |
| Alternative Product SKU | 31248000 |
| Manufacturer | Wohner |
| Packed Quantity | 10 |
