31247 Wohner cylindr. fuse link 6 A
MPN: 31247
Alt. SKU: 31247000
Special Price
£21.67
£18.06
Regular Price
£27.08
Why Choose the Eaton Cylindrical Fuse Link 6 A (31247)?
The Eaton Cylindrical Fuse Link 6 A is a reliable and high-performance component designed specifically for control transformer applications. Featuring a time delay operation and Class CC rating, this fuse link ensures optimal protection against overloads and short circuits in electrical systems. Manufactured with durable porcelain material and being halogen free, it meets stringent safety and environmental standards. Its approvals from UL and CSA further guarantee compliance and quality assurance for industrial use.
Key Benefits
- Time delay operation provides protection against temporary overloads without nuisance blowing.
- Class CC rating ensures compact size with high interrupting capacity for efficient circuit protection.
- Rated for 600 V AC and 6 A current, suitable for a wide range of control transformer applications.
- Constructed from porcelain, a non-conductive material that does not carry current, enhancing safety.
- Halogen free design supports environmentally responsible installations.
- Certified by UL and CSA, meeting rigorous North American safety standards.
Technical Specifications
- Item number: 31247
- Description: cylindr. fuse link 6 A
- Rated current: 6 A
- Rated voltage AC: 600 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 10 x 10 x 38 mm
- Weight: 0.8 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-1
- Approval: UL 248-4
- Approval: CSA , UL
- Approval: type number: FNQ-R
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What applications is this fuse link suitable for?
This fuse link is designed for control transformer applications, providing reliable protection in such circuits.
Does the fuse link carry current?
The fuse link itself is a mechanical component made of porcelain, which does not carry current. The fuse element inside is responsible for current interruption.
What does time delay operation mean?
Time delay operation allows the fuse to withstand temporary current surges without blowing, preventing unnecessary interruptions in the circuit.
Is this fuse link environmentally friendly?
Yes, it is halogen free, supporting environmentally responsible installations.
Are there certifications for this product?
Yes, it is approved by UL and CSA, ensuring compliance with North American safety standards.
| Manufacturer Part Number | 31247 |
|---|---|
| Barcode | 4021267312473 |
| Height | 10mm |
| Width | 10mm |
| Depth | 38mm |
| Alternative Product SKU | 31247000 |
| Manufacturer | Wohner |
| Packed Quantity | 10 |
