31246 Wohner cylindr. fuse link 4 A
MPN: 31246
Alt. SKU: 31246000
Special Price
£21.67
£18.06
Regular Price
£27.08
Why Choose the Eaton Cylindrical Fuse Link 4 A (31246)?
The Eaton Cylindrical Fuse Link 4 A is designed for reliable protection in control transformer applications. Its time delay operation ensures selective tripping, preventing nuisance interruptions. Manufactured with high-quality porcelain and halogen-free materials, this fuse link guarantees durability and safety in demanding electrical environments. Certified to stringent UL and CSA standards, it offers peace of mind for industrial and commercial installations.
Key Benefits
- Time delay feature allows temporary current surges without blowing, ideal for control transformers.
- Rated for 600 V AC and 4 A current, suitable for a wide range of electrical systems.
- Compact dimensions (10 x 10 x 38 mm) enable easy installation in tight spaces.
- Constructed from porcelain, a robust and heat-resistant material that does not carry current itself.
- Halogen-free design supports environmentally responsible installations.
- High short-circuit current rating (SCCR) of 200 kA ensures protection against severe faults.
- Complies with UL 248-1, UL 248-4, and CSA standards for assured quality and safety.
Technical Specifications
- Item number: 31246
- Description: cylindr. fuse link 4 A
- Rated current: 4 A
- Rated voltage AC: 600 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 10 x 10 x 38 mm
- Weight: 0.8 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-1
- Approval: UL 248-4
- Approval: CSA , UL
- Approval: type number: FNQ-R
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What applications is this fuse link suitable for?
This fuse link is ideal for control transformer applications requiring time delay protection.
Does the fuse link carry current?
No, the porcelain body of the fuse link is an insulating material and does not carry current itself.
What does the time delay operation mean?
Time delay allows the fuse to withstand temporary current surges without blowing, preventing unnecessary interruptions.
Is this fuse link environmentally friendly?
Yes, it is halogen free, supporting safer disposal and reduced environmental impact.
What certifications does this fuse link have?
It is certified under UL 248-1, UL 248-4, CSA, and meets type number FNQ-R requirements.
| Manufacturer Part Number | 31246 |
|---|---|
| Barcode | 4021267312466 |
| Height | 10mm |
| Width | 10mm |
| Depth | 38mm |
| Alternative Product SKU | 31246000 |
| Manufacturer | Wohner |
| Packed Quantity | 10 |
Write Your Own Review
