31245 Wohner cylindr. fuse link 2 A

Why Choose the Eaton Cylindrical Fuse Link 2 A (31245)?

The Eaton Cylindrical Fuse Link 2 A is a reliable and high-quality electrical protection device designed specifically for control transformer applications. With a robust porcelain construction and halogen-free materials, this fuse link ensures safety and durability under demanding conditions. Its time delay operation and Class CC rating provide excellent protection against short circuits and overloads, making it an essential component for industrial electrical systems.

Key Benefits

• Rated for 600 V AC and 2 A current, suitable for a wide range of control transformer applications.
• Time delay feature allows temporary overloads without nuisance blowing, enhancing system reliability.
• Compact dimensions (10 x 10 x 38 mm) enable easy installation in confined spaces.
• Constructed from durable porcelain material, ensuring long service life and mechanical strength.
• Halogen-free design supports environmental safety and compliance with modern regulations.
• Certified to UL 248-1, UL 248-4, and CSA standards, guaranteeing high safety and performance levels.
• High short-circuit current rating (SCCR) of 200 kA for robust fault protection.

Technical Specifications

• Item number: 31245
• Description: cylindr. fuse link 2 A
• Rated current: 2 A
• Rated voltage AC: 600 V
• Rated frequency: 50 / 60 Hz
• Dimensions (W x H x D): 10 x 10 x 38 mm
• Weight: 0.8 kg/100
• Material: Porcelain
• Halogen free: Yes
• Approval: UL 248-1
• Approval: UL 248-4
• Approval: CSA , UL
• Approval: type number: FNQ-R
• Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
• Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
