31244 Wohner cylindr. fuse link 1 A

Why Choose the Eaton Cylindrical Fuse Link 1 A (31244)?

The Eaton Cylindrical Fuse Link 1 A (31244) is a reliable and high-quality electrical protection component designed for control transformer applications. With a time delay operation and Class CC rating, it ensures precise and safe circuit protection. Manufactured from durable porcelain and halogen-free materials, this fuse link meets stringent safety and environmental standards. Its approvals from UL and CSA guarantee compliance with international safety regulations, making it an excellent choice for industrial and commercial electrical installations.

Key Benefits

• Time delay operation to prevent nuisance tripping during temporary overloads.
• Rated for 600 V AC and 1 A current, suitable for control transformer circuits.
• Compact dimensions (10 x 10 x 38 mm) for easy integration into electrical panels.
• Constructed from porcelain, providing excellent insulation and mechanical strength.
• Halogen-free materials for enhanced environmental safety.
• Certified by UL and CSA, ensuring compliance with industry standards.
• High short-circuit current rating (SCCR) of 200 kA for robust protection.

Technical Specifications

• Item number: 31244
• Description: cylindr. fuse link 1 A
• Rated current: 1 A
• Rated voltage AC: 600 V
• Rated frequency: 50 / 60 Hz
• Dimensions (W x H x D): 10 x 10 x 38 mm
• Weight: 0.8 kg/100
• Material: Porcelain
• Halogen free: Yes
• Approval: UL 248-1
• Approval: UL 248-4
• Approval: CSA , UL
• Approval: type number: FNQ-R
• Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
• Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
