31241 Wohner cylindr. fuse link 20 A
MPN: 31241
Alt. SKU: 31241000
Special Price
£17.93
£14.94
Regular Price
£22.40
cylindr. fuse link 20 A (31241) by Eaton
Ensure reliable branch circuit protection with the Eaton cylindr. fuse link 20 A, a fast acting Class CC fuse link designed for 600 V AC systems. Manufactured with high-quality porcelain and halogen-free materials, this fuse link offers robust performance and safety compliance for industrial electrical installations.
Why Choose the Eaton cylindr. fuse link 20 A?
- Fast acting Class CC fuse link providing superior protection for branch circuits.
- Rated for 600 V AC and compatible with 50 / 60 Hz systems.
- Constructed from durable porcelain material ensuring long-lasting reliability.
- Halogen free design supports environmentally responsible installations.
- Certified to multiple safety standards including UL 248-1, UL 248-4, and CSA approvals.
Key Benefits
- High interrupting rating of 200 kA SCCR for enhanced safety in fault conditions.
- Compact dimensions (10 x 10 x 38 mm) fit easily into standard fuse holders.
- Lightweight design (0.8 kg per 100 units) facilitates handling and installation.
- Fast acting operation minimises damage to electrical equipment during faults.
- Comprehensive technical documentation and CAD data available for seamless integration.
Technical Specifications
- Item number: 31241
- Description: cylindr. fuse link 20 A
- Rated current: 20 A
- Rated voltage AC: 600 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 10 x 10 x 38 mm
- Weight: 0.8 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-1
- Approval: UL 248-4
- Approval: CSA , UL
- Approval: type number: KTK-R
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What type of protection does this fuse link provide?
This fuse link provides fast acting protection for branch circuits, helping to prevent damage from overloads and short circuits.
Is this fuse link suitable for DC applications?
No, this fuse link is rated for AC voltage up to 600 V and is not specified for DC applications.
What materials are used in the construction of this fuse link?
The fuse link is made from porcelain and is halogen free, ensuring durability and environmental safety.
Does this fuse link carry current?
Yes, as an electrical fuse link, it carries current and interrupts the circuit when necessary to protect equipment.
Where can I find technical documentation and CAD data?
Technical information, characteristics, and EU declaration of conformity are available via provided download links. CAD data can be accessed through WSCAD Universe and PartCommunity platforms.
| Manufacturer Part Number | 31241 |
|---|---|
| Barcode | 4021267312411 |
| Height | 10mm |
| Width | 10mm |
| Depth | 38mm |
| Alternative Product SKU | 31241000 |
| Manufacturer | Wohner |
| Packed Quantity | 10 |
