31240 Wohner cylindr. fuse link 15 A

Why Choose the Eaton Cylindr. Fuse Link 15 A (31240)?

The Eaton Cylindr. Fuse Link 15 A (31240) is a reliable and fast-acting fuse link designed for branch circuit protection. With a rated voltage of 600 V AC and a current rating of 15 A, it ensures effective protection for your electrical systems. Manufactured from durable porcelain and halogen-free materials, this fuse link meets stringent safety standards and approvals including UL and CSA certifications. Its compact dimensions and robust construction make it an ideal choice for industrial and commercial applications requiring Class CC fuse protection.

Key Benefits

• Fast acting operation for quick circuit interruption and enhanced safety.
• Rated for 600 V AC and 15 A current, suitable for a wide range of branch circuit applications.
• Constructed from high-quality porcelain, ensuring durability and reliability.
• Halogen-free materials promote environmental safety and reduce toxic emissions.
• Complies with multiple international approvals including UL 248-1, UL 248-4, and CSA standards.
• Compact size (10 x 10 x 38 mm) allows for easy integration into existing fuse holders.

Technical Specifications

• Item number: 31240
• Description: cylindr. fuse link 15 A
• Rated current: 15 A
• Rated voltage AC: 600 V
• Rated frequency: 50 / 60 Hz
• Dimensions (W x H x D): 10 x 10 x 38 mm
• Weight: 0.8 kg/100
• Material: Porcelain
• Halogen free: Yes
• Approval: UL 248-1
• Approval: UL 248-4
• Approval: CSA , UL
• Approval: type number: KTK-R
• Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
• Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
