31236 Wohner cylindr. fuse link 2 A
MPN: 31236
Alt. SKU: 31236000
Special Price
£18.67
£15.56
Regular Price
£23.34
Why Choose the Eaton Cylindrical Fuse Link 2 A (31236)?
The Eaton Cylindrical Fuse Link 2 A (31236) is a reliable and fast-acting fuse designed for branch circuit protection. Manufactured with high-quality porcelain material, it ensures durability and safety in electrical installations. Its Class CC rating and 600 V AC voltage capacity make it suitable for a wide range of industrial applications. With halogen-free construction and multiple international approvals, this fuse link guarantees compliance and environmental responsibility.
Key Benefits
- Fast acting operation for quick circuit interruption and enhanced protection.
- Rated for 2 A current and 600 V AC voltage, ideal for branch circuit protection.
- Constructed from durable porcelain material, ensuring long-lasting performance.
- Halogen-free design supports environmentally friendly installations.
- Complies with UL 248-1, UL 248-4, CSA, and other international standards.
- Compact dimensions (10 x 10 x 38 mm) for easy integration into existing systems.
Technical Specifications
- Item number: 31236
- Description: cylindr. fuse link 2 A
- Rated current: 2 A
- Rated voltage AC: 600 V
- Rated frequency: 50 / 60 Hz
- Dimensions (W x H x D): 10 x 10 x 38 mm
- Weight: 0.8 kg/100
- Material: Porcelain
- Halogen free: Yes
- Approval: UL 248-1
- Approval: UL 248-4
- Approval: CSA , UL
- Approval: type number: KTK-R
- Approval: UL file: E4273, UL category (for USA): JDDZ https://www.ul.com
- Approval: CSA file: 53787, CSA class: 1422-02 https://directories.csa-international.org
Frequently Asked Questions
What is the primary function of this fuse link?
This fuse link provides fast-acting protection for branch circuits by interrupting overcurrent conditions to prevent damage to electrical equipment.
Is this fuse link suitable for DC voltage applications?
No, this fuse link is rated for AC voltage up to 600 V and is not specified for DC voltage use.
Does the fuse link carry current continuously?
Yes, as an electrical fuse link, it carries current under normal operating conditions and interrupts current only during fault conditions.
Is the fuse link environmentally friendly?
Yes, it is halogen-free, supporting environmentally responsible installations.
Where can I find technical documentation for this product?
Technical documents such as general technical information, characteristics, and EU declaration of conformity are available for download from the manufacturer's website.
| Manufacturer Part Number | 31236 |
|---|---|
| Barcode | 4021267312367 |
| Height | 10mm |
| Width | 10mm |
| Depth | 38mm |
| Alternative Product SKU | 31236000 |
| Manufacturer | Wohner |
| Packed Quantity | 10 |
