2811934 Cembre TSS380Y/G TERMOSTRIP

TSS380Y/G 2:1 Heat Shrink Tubing (36.5mm - 17.5mm, Yellow/Green)

The TSS380Y/G heat shrink tubing provides reliable insulation and protection for wiring and components in demanding industrial environments. With a 2:1 shrink ratio, this yellow/green tubing offers excellent flexibility and performance, meeting stringent industry standards including UL 224, IEC 243, and RoHS compliance.

Why Choose TSS380Y/G Heat Shrink Tubing?

Ensure long-term protection and reliability for your electrical systems with this high-performance heat shrink tubing. Ideal for panel building, industrial maintenance, and a wide range of electrical applications, the TSS380Y/G offers superior durability and compliance.

Key Features

• 2:1 Shrink Ratio: Provides a tight, secure fit over a wide range of cable and component sizes.
• Wide Operating Temperature Range: Performs reliably from -55°C to 125°C.
• Halogen-Free: Enhances safety and minimizes environmental impact.
• UL, IEC, and RoHS Compliant: Meets rigorous industry standards for safety and quality.
• Yellow/Green Color: Provides clear visual identification for grounding applications.

Technical Specifications

• SKU: 2811934
• Electrocode: 36D1
• ETIM Class 7: Shrink tubing [EC000217]
• Customs Code: 39173200
• Inner Diameter (Pre-Shrink): 36.5mm
• Inner Diameter (Post-Shrink): 17.5mm
• Thickness (Post-Shrink): 1mm
• Shrink Ratio: 2:1
• Minimum Shrinkage Temperature: 70°C
• Full Shrinkage Temperature: 110°C
• Operating Temperature: -55°C to 125°C
• Tensile Strength (Post Thermal Aging): 7.3 N/mm²
• Elongation at Break (Post Thermal Aging): 100%
• Dielectric Strength: 15 kV/mm (IEC 243)
• Flammability: VW-1 (UL 224)
• Material: Polyolefin
• Halogen-Free: Yes
• ROHS Compliant: Yes
• Coil Length: 1.22m
• Packaging: Box (4 pieces per box)
• Gross Weight: 152.4g per piece

Applications

• Protecting and insulating wiring harnesses in industrial control panels
• Cable bundling and organization
• Repairing damaged cable insulation
• Providing strain relief for electrical connections
• Color-coding and identification of wires and cables
