2811652 Cembre TSS32BK TERMOSTRIP

The TSS32BK heat shrink tubing offers reliable insulation and protection for your electrical wiring in demanding environments. With a 2:1 shrink ratio and a 3mm pre-shrink diameter, this black polyolefin tubing provides a tight, secure fit for a range of applications, meeting stringent industry standards including UL 224, VW-1 flammability rating, and RoHS compliance.

Why Choose TSS32BK Heat Shrink Tubing?

Designed for professional electricians, panel builders, and maintenance engineers, the TSS32BK heat shrink tubing ensures long-lasting performance and peace of mind. Its robust material and compliance with key industry regulations make it ideal for various industrial and commercial applications.

Key Features

• 2:1 Shrink Ratio, providing a snug fit around wires and components.
• 3mm Pre-shrink Inner Diameter, accommodating a variety of wire sizes.
• Halogen-free Polyolefin material for safe and environmentally friendly operation.
• Operating Temperature range from -55°C to 125°C, suitable for extreme environments.
• Compliant with UL 224, VW-1 flammability, and RoHS standards, ensuring quality and safety.

Technical Specifications

• Part Number: 2811652
• Electrocode: 36D1
• ETIM Class 7: Shrink tubing [EC000217]
• Customs Code: 39173200
• Minimum Operating Temperature: -55°C
• Maximum Operating Temperature: 125°C
• Tensile Strength After Thermal Aging: 7.3 N/mm²
• Elongation at Break After Thermal Aging (UL): 100%
• Heat Resistance (UL): No failure
• Low Temperature Flexibility (UL 224): No failure
• Dielectric Strength (IEC 243): 15 kV/mm
• Insulation Resistance (UL 224): No perforation at 2500V
• Volume Resistance (IEC 93): 10^14
• Flammability (UL 224): VW-1
• Material: Polyolefin
• Halogen Free: Yes
• Shrinkage Ratio: 2:1
• Minimum Shrinkage Temperature: 70°C
• Full Shrinkage Temperature: 110°C
• Coil Length: 1.22 m
• Inner Diameter Pre-Shrinkage: 3 mm
• Inner Diameter After Shrinkage: 1.3 mm
• Thickness After Shrinkage: 0.45 mm
• Color: Black
• Packaging: Box (30 pieces)
• Gross Weight: 10.53 kg (Box of 30)
• RoHS Compliant: Yes

Applications

• Wire Harnessing
• Cable Insulation and Protection
• Strain Relief
• Environmental Sealing
• Component Identification
