2808864 Cembre PKD7510 INSULATED END SLEEVE (GREY)

Why Choose the PKD7510 Insulated End Sleeve?

The PKD7510 Grey Insulated End Sleeve (SKU: 2808864) provides a secure and reliable crimp connection for conductors up to 0.75mm². Engineered for demanding applications, its robust construction, high-temperature resistance, and compliance with DIN 46 228/4 make it the ideal choice for professional electricians, panel builders, and maintenance engineers.

Key Features

• High-Temperature Performance: Operates reliably from -20°C to 105°C, with short-term tolerance up to 130°C.
• Durable Construction: Electrolytic copper conductor with tin plating ensures excellent conductivity and corrosion resistance.
• Safe and Compliant: Meets DIN 46 228/4, UL 94 V2 flammability rating, and halogen-free for enhanced safety.
• Easy Installation: Designed for easy insertion and crimping, saving valuable installation time.
• Efficient Packaging: Available in boxes of 500 and 10,000 pieces, optimizing storage and inventory management.

Technical Specifications

• Part Number: PKD7510
• SKU: 2808864
• Operating Temperature Range: -20°C to 105°C (130°C short-term)
• Standard: DIN 46 228/4
• Flammability Rating: UL 94 V2
• Conductor Material: Electrolytic copper (99.95% purity) with tin plating (min. 3µm)
• Insulation Material: Polyamide PA6 (grey)
• Dielectric Strength: 16.5 kV/mm
• Halogen-Free: Yes
• Wire Cross-Section: 0.75mm²
• Dimensions (L x Ø2 x Ø3 x C x P): 16mm x 2.8mm x 1.2mm x 6mm x 10mm
• Stripping Length: 10mm

Applications

• Industrial control panels
• Building automation systems
• Machinery wiring
• Maintenance and repair applications
